AMP Research PowerStep 76332-01A Installation Manual page 5

A M P R E S E A R C H P O W E R S T E P
Locate mounting points; first and last set of studs on the inner sill. Motor Linkage mounts toward
the front of the truck and Idler mount toward the rear. Driver side shown below.
Driver Side Rear Stud Location
1
Mount front drive linkage assembly. Install the nut(12),
on the motor side of the linkage, as the linkage goes
on, due to little install clearance. An open end wrench
is needed at shallow angles, down and at the opposite
angle upward.
Repeat for passenger side. Make sure linkages sit
square, fully resting on studs before tightening. Torque
to 16 ft. lbs (22Nm).
2
Mount rear Idler linkage assembly with three nuts(12). Repeat for passenger side. Make sure
linkages sit square, fully resting on studs before tightening. Torque to 16 ft. lbs (22Nm).
4 3
www.amp-research.com
T M
Idler Linkage (Rear)
5/9
– F O R D E X P E D I T I O N
Driver Side Front Stud Location
Drive Linkage (Front)
IM76332 rev 08.02.19
