OPERATION DIAGRAM

The Remote View Door Phone (RVDP) is designed to deliver live video directly to your smart mobile
devices after visitor have pressed the communication button on the door unit. The RVDP app will
allow you to see live video, speak to the visitor, manually capture snapshot/video and even open the
door (3rd party door lock device required) for the visitor.
1 Visitor Press Push button
1
868 / 916 Hz
Door Chime
3
Receiving Notification
•Live-Video w/Incoming Audio
•Two-Way PTT Audio
•Video Event List
•Remote Door Unlock Trigger
(3rd party device)
3rd Party 3rd Party 3rd Party
Gate Door Lock Door Chime
Note:
If you have changed the Wi-Fi or wish the camera could connect to different router, please
remove the camera from the device list first and reset the camera to default. Follow the
installation process and setup as new camera.
Visitor Press Push button
3rd Party
Door Chime
Connection with
Wi-Fi Network
Wi-Fi 2.4GHz
Connection with
Wi-Fi Network
Video Door Phone
Wi-Fi Router
Cable Connection
2 Activate Doorbell Music & App
Notification Alert
•Auto Visitor Video Record
Connect
Wi-Fi Router
2 Activate Doorbell Music & App
Notification Alert
•Auto Visitor Video Record
JSW Connectivity Server
Field Proven Secure Technology
• Push Notification Management
• Direct/Relay Connectivity Management
9
JSW Connectivity Server
Field Proven Secure Technology
• Push Notification Management
• Direct/Relay Connectivity Management
Control Notify
APP
3
Receiving Notification
•Live-Video w/Incoming Audio
•Two-Way PTT Audio
•Video Event List
•Remote Door Unlock Trigger
(3rd party device)
