EDID Table
Number
0 Customize EDID #1
1 Customize EDID #2
2 1024x768
3 1280x720
4 1280x1024
5 1366x768
6 1600x900
7 1680x1050

EDID Settings

Step1: Refer to EDID list at last page and find the number of which EDID is needed. (0~F)
Step2: Rotate the rotary dip switch arrow
Step3: Click "SET" button, and the two blue LEDs will flash quickly.
Step4: Wait for HE04SET to restart, and the process of EDID setting is done.
Customize EDID Settings
Step1: Connects display and loop out port through HDMI cable.
Step2: Press and Hold "SET" button for approximately 3 second, and the two blue LEDs will flash
slowly then quickly.
Step3: Wait for HE04SET to restart, and the process of copying EDID is done.
Caution:
1. The wiring must be away from any equipment with electromagnetic wave, i.e.: mobile phone,
microwave, radio equipment, fluorescent lamp, high voltage power lines.
2. HE04SEK isn't networking device, please do not connect with Ethernet device to avoid
damages.

Package Contents:

1 x HE04SET
4 x HE01SER
1 x DC12V 1A power supply
4 x Rubber cushions
2 x Screws/ Screw hole plugs
EDID
Number
to the selected number.
1920x1080
8
1920x1200
9
720p 50Hz LPCM 2CH
A
720p 60Hz LPCM 2CH
B
1080p 50Hz LPCM 2CH
C
1080p 60Hz LPCM 2CH
D
1080p 50Hz MULTI
E
1080p 60Hz MULTI
F
EDID
