- Page 1 Manual bintec elmeg GmbH bintec H2 Automotive+ Installation Manual Copyright© bintec Dm660-I Version 2.0 06/2019 bintec elmeg GmbH bintec H2 Automotive+...
- Page 2 This publication is subject to change. bintec elmeg GmbH offers no warranty whatsoever for information contained in this manual. bintec elmeg GmbH is not liable for any direct, indirect, collateral, consequential or any other damage connected to the delivery, supply or use of this manual.
-
Page 3: Table Of Contents
Table of Contents bintec elmeg GmbH Table of Contents Chapter 1 About this manual ....... . . 1 Supported devices . - Page 4 Table of Contents bintec elmeg GmbH 3.6.4 Positioning the antennas....... .
- Page 5 Table of Contents bintec elmeg GmbH A.4.4 Wireless LAN interface ....... .
-
Page 6: About This Manual
(such as its technical specification, description, etc.) can be found in the section covering that particular com- ponent. 1.7 Technical support bintec elmeg GmbH offers a technical support service. Regular software upgrades are available for maintenance and new features. Contact information: Web: http://www.bintec-elmeg.com... -
Page 7: Related Documentation
1 About this manual bintec elmeg GmbH Email: support@bintec-elmeg.com 1.8 Related documentation bintec Dm704-I Configuration and Monitoring. bintec Dm748-I Software Updating. bintec-Dm771-I Wireless LAN Interface. bintec Dm781-I Cellular Interface. bintec Dm812-I GPS. Note The manufacturer reserves the right to change and/or improve the software and hardware of this product or change the specifications in this manual without notice. -
Page 8: Bintec H2 Automotive
2 bintec H2 Automotive+ bintec elmeg GmbH Chapter 2 bintec H2 Automotive+ 2.1 Introduction This manual explains how to install and connect the bintec H2 Automotive+ router. bintec H2 Automotive+ Fig. 1: 2.1.1 Power supply For further information on the bintec H2 Automotive+ power supply, please see Power Source on page 9. -
Page 9: Components And Power Supply
3 Components and power supply bintec elmeg GmbH Chapter 3 Components and power supply This chapter describes the chassis and components of the bintec H2 Automotive+. The following topics are covered: • Components • Assembly instructions • Power supply • RESET button •... - Page 10 3 Components and power supply bintec elmeg GmbH LAN1 to LAN4 connectors for 4-port Gigabit Ethernet switch. AUX. DB9 connector providing access to the device's local console for configuration and monitoring purposes. RST. Reset button. For further information on how the reset button works, please see...
-
Page 11: Rear Panel
3 Components and power supply bintec elmeg GmbH formation as follows: Off -> system stopped. Red -> the interface is unavailable because it is being installed, it is disabled (shutdown), or it has failed a self-test. Amber -> idle. • Rapid blinking. The device has not, or cannot register, with the network. -
Page 12: Mounting Options
3 Components and power supply bintec elmeg GmbH bintec H2 Automotive+ Fig. 5: : Rear panel The rear panel components include: Table 3: Rear panel components Item Description SIM trays (1 to 4). For more information on how to install SIM cards and assign them to each... -
Page 13: Outline Drawing
3 Components and power supply bintec elmeg GmbH • For sheet metal installation, use #8 self-drilling screws. • For tapped holes, use M4 machine screws. Warning If the screws are not properly anchored, the strain of the cables connected to the router could pull the router out. -
Page 14: Power Source
3 Components and power supply bintec elmeg GmbH Outline drawing Fig. 8: 3.3 Power Source The bintec H2 Automotive+ is powered through direct current (DC). Fig. 9: Power connector bintec H2 Automotive+... -
Page 15: Connecting The Power Cable To The Vehicle
3 Components and power supply bintec elmeg GmbH Workplace Conditions. Main Characteristics • Avoid moist and/or dusty locations. • Avoid direct exposure to sunlight and any other heat sources. Do not place the device among papers, magazines or other items that could hinder natural air circulation. -
Page 16: Connecting The Power Cable To The Device
The cable features may vary depending on the recommendations in the country in which the equipment is installed. The cable must always be 18 AWG or above. 3.3.3.1 Power cord pinout bintec elmeg GmbH provides a 100cm 23 AWG power cord with the following pin assignment. Color Signal... -
Page 17: Reset Button
3 Components and power supply bintec elmeg GmbH switch. When power is applied to the device - BATTERY (+) /VCC -, the device remains off. It will not turn on until the ignition pin - ACC / IGNITION - sends a signal (+12 V or +24 V). -
Page 18: Rebooting The Device
3 Components and power supply bintec elmeg GmbH 3.4.1 Rebooting the device Once the device is operating normally, press the RST button to reboot. 3.4.2 Default configuration The RST button allows you to restore your router to its default configuration. Follow these steps to reset your router: •... -
Page 19: 4-Port Ethernet Switch
3.6.2 Connecting to a WLAN antenna The bintec H2 Automotive+is equipped with up to eight SMA-RP connectors for WLAN (Wi-Fi) antennas (on mod- els with this interface). Name... -
Page 20: Connecting To A Wwan Antenna
For optimum performance, please use the radio frequency accessories (antennas and cables) recommended by bintec elmeg GmbH bintec elmeg GmbH has a range of accessories that allow bintec H2 Automotive+ routers to be installed at different locations. bintec H2 Automotive+... -
Page 21: Positioning The Antennas
3 Components and power supply bintec elmeg GmbH Note Antennas must not be directly connected to the bintec H2 Automotive+ router. They should be at least 50 cm away. The following image shows the position of the WWAN antenna connectors. -
Page 22: Connecting The Gps Antenna
3 Components and power supply bintec elmeg GmbH 3G USB Connector Fig. 16: Note To see a list of compatible external USB modems, please visit: http://www.bintec-elmeg.com 3.6.6 Connecting the GPS antenna The bintec H2 Automotive+ has an FME connector to connect an active GPS antenna (on models equipped with this interface). -
Page 23: Configuration Connection
3 Components and power supply bintec elmeg GmbH 3.6.7 Configuration connection The front panel of the bintec H2 Automotive+ router includes a DB9 female connector labeled AUX that can be used as a router configuration port or as a V.24 asynchronous serial port (using a configuration command). The be- havior or functionality of this interface must be configured in advance. -
Page 24: Installing The Sim
3 Components and power supply bintec elmeg GmbH Warning This router is compatible with 1.8 V and 3 V SIM cards. Do not install SIMs that do not support these voltages. Never install a SIM card when the device is switched on. - Page 25 3 Components and power supply bintec elmeg GmbH Inserting the SIMs Fig. 20: bintec H2 Automotive+...
-
Page 26: Compliance
4 Compliance bintec elmeg GmbH Chapter 4 Compliance 4.1 Manufacturer information Brand bintec Manufacturer bintec elmeg GmbH Country Germany Postal Address Suedwestpark 94 90449 Nuremberg Germany International Phone +49 - 911 - 9673 0 4.2 Risk identification WARNING: Signal word used to designate a potentially dangerous situation that may cause severe injuries or death if not avoided. - Page 27 4 Compliance bintec elmeg GmbH This device is compatible with 1.8 V and 3 V SIM cards. Do not install SIM cards that do not support these voltages. Este equipo es compatible con SIMs de 1.8V y 3V. No instale SIMs que no so- porten estas tensiones.
- Page 28 4 Compliance bintec elmeg GmbH The electric current in power cables, telephone lines and communication cables is dangerous. To prevent electric shocks, before installing, handling or opening the equipment covers, connect and disconnect the cables following the steps set forth Connecting the data on page 13.
-
Page 29: Weee Information
2017) Directive 2011/65/EU (RoHS) Spanish (ES) Español Por la presente, bintec elmeg GmbH declara que el tipo de equipo radioeléctrico bintec H2 Automotive+ es conforme con: Directiva 1999/5/EC (hasta el 12 de junio de 2017) y Directiva 2014/53/EU (desde el 13 de junio 2017) -
Page 30: National Restrictions
Not all countries have implemented the harmonized use of 5 GHz for the implementation of Wireless Access Systems/Radio Local Area Networks (WAS//RLANs) yet. Since countries set their own regulations, bintec elmeg GmbH recommends that local authorities are consulted as regulations may change from time to time. -
Page 31: Radio Frequency Interference Requirements
4 Compliance bintec elmeg GmbH 4.8.3 Radio Frequency Interference Requirements This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. The FCC requires this product to be used indoors to reduce the potential for harmful interference to co-channel Mo- bile Satellite systems. -
Page 32: Appendix A Technical Information
Technical information bintec elmeg GmbH Appendix A Technical information A.1 Troubleshooting The following table lists common problems and potential solutions to help you when installing your router. Please contact your dealer for further information if you are unable to solve a problem. - Page 33 Technical information bintec elmeg GmbH A.2.2.1 Configuration using the local console (AUX connector) The front panel of the bintec H2 Automotive+ includes a DB9 female connector labeled AUX. This provides access to the router's local console and can operate as an asynchronous serial port. The behavior or functionality of this in- terface must be configured in advance.
-
Page 34: Connectors
• Start a Telnet session from the IP terminal to IP address 192.168.1.1 ( bintec H2 Automotive+ default address). • The default configuration does not ask for login credentials (user/password) to access the console. For additional information on configuring your device, refer to the user manuals provided by bintec elmeg GmbH on the documentation CD or website. -
Page 35: Wlan Connector
Technical information bintec elmeg GmbH A.3.4 WLAN Connector Devices equipped with this interface have an SMA-RP female coaxial WLAN connector installed. SMA-RP Female Internal RF in/out External A.3.5 GPS Connector Devices equipped with this interface have an FME male GPS connector installed. -
Page 36: Technical Specifications
Technical information bintec elmeg GmbH A.4 Technical specifications A.4.1 Hardware architecture PROCESSORS Freescale QorIQ processor. MEMORY 256 MB in DDR3. STORAGE UNIT FLASH Memory (32 Mbytes). A.4.2 LAN interface PROTOCOLS Ethernet (802.3). PORTS 4-port switch managed through MDI/MDX self-detection. SPEED 10/100/100 Mbps (BaseT). -
Page 37: Wireless Wan Interface
Technical information bintec elmeg GmbH A.4.3 Wireless WAN interface WWAN Standard/Bands MC7455: • LTE: • FDD. B1-B5, B7, B12, B13, B17, B20, B25, B26, B29, B30 • TDD: B41 • WCDMA: B1, B2, B3, B4, B5, B8 MC7430: • LTE: •... - Page 38 Technical information bintec elmeg GmbH • HSPA+ Cat 24/6: 42Mbps/5.76Mbps MC7304: • LTE Cat 3. 100Mbps/50Mbps • HSPA+ Cat 24/6: 42Mbps/5.76Mbps • EDGE: 236Kbps MC7354: • LTE Cat 3. 100Mbps/50Mbps • HSPA+ Cat 24/6: 42Mbps/5.76Mbps • CDMA 1xRTT: 153Kbps, EV-DO: 3.1Mbps/1.8Mbps •...
-
Page 39: Wireless Lan Interface
Technical information bintec elmeg GmbH A.4.4 Wireless LAN interface WLAN standards IEEE 802.11ac complaint and backward compatible with 802.11a/b/g/n. CONNECTOR Up to eight SMA-RP female connectors. Frequency range 2.4 GHz: 2412 ~ 2472 MHz. 5 GHz: 5180 ~ 5825 MHz. - Page 40 Technical information bintec elmeg GmbH Data rates for 802.11ac, Long MSC0 27 Mbps; MSC1 54 Mbps; MCS2 81 Mbps; MCS3 108 Mbps; MCS4 162 Guard (800ns), 40 MHz with two Mbps; MSC5 216 Mbps; MCS6 243 Mbps; MCS7 270 Mbps; MCS8 324 Mbps;...
-
Page 41: Gps Interface
3.3 V Active. Passive. A.4.6 USB Interface 3G USB MODEMS Please visit the bintec elmeg GmbH website (http://www.bintec-elmeg.com) for a list of supported 3G USB modems. SPEED The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de- pends on the 3G USB modem used. -
Page 42: Power
Technical information bintec elmeg GmbH A.4.8 Power INPUT VOLTAGE Input: 9-36 V DC Nominal: 12-24 V DC INPUT CURRENT 2 A@12Vdc MAXIMUM POWER With a WWAN module installed: 12 W With a WWAN+WIFI module installed: 15 W With two WWAN+WIFI modules installed: 19 W... -
Page 43: Appendix Bce Radio Information
CE Radio information bintec elmeg GmbH Appendix B CE Radio information This section contains information on some of the European radio frequencies that are currently in force across Europe. Country-specific bands are available upon request. B.1 RF WAN specifications LTE/WCDMA/GSM connectivity is provided by Sierra Wireless modules. The exact modules installed will depend on your particular router model. - Page 44 CE Radio information bintec elmeg GmbH Band 3 Tx: 1710–1785 MHz +23 dBm ± 1 dB Rx: 1805–1880 MHz Band 7 Tx: 2500–2570 MHz +22 dBm ± 1 dB Rx: 2620–2690 MHz Technology: LTE. EC25-E specifications. Bands Frequencies Conducted Transmit Power...
-
Page 45: Wlan Specifications
CE Radio information bintec elmeg GmbH Band 8 Tx: 880–915 MHz +23 dBm ± 1 dB Rx: 925–960 MHz Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+. EC25-E specifications. Bands Frequencies Conducted Transmit Power Band 1 Tx: 1920-1980 MHz +24 dBm +1/-3 dB... - Page 46 CE Radio information bintec elmeg GmbH Type of modulation 2.4 GHz: 802.11b: DSSS 802.11g/n: OFDM. 5.0 GHz: 802.11a/n/ac: OFDM. Conducted Note: The maximum RF power setting may vary depending on country-specific regula- tions. Output Power. 802.11 bg: 18dBm @54Mbps. (tolerance ± 2 dB) 802.11n HT20: 18dBm @MCS15.
-
Page 47: Appendix Cfcc Radio Information
(regardless of its nature, includ- ing personal injuries, death, or loss of property). bintec elmeg GmbH accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the equipment, or for failure of the Radio Wireless module to transmit or receive such data. -
Page 48: Lte Mc7354 Wwan Frequency Requirements
FCC Radio information bintec elmeg GmbH 777.0 - 787.0 MHz 0.247 W 777.0 - 787.0 MHz 0.227 W 1710.0 - 1755.0 MHz 0.249 W 1710.0 - 1755.0 MHz 0.217 W 1710.0 - 1755.0 MHz 0.218 W 1850.0 - 1915.0 MHz 0.247 W... -
Page 49: Wle600Vx Wlan Frequency Requirements
FCC Radio information bintec elmeg GmbH 1710.0 - 1755.0 MHz 0.202 W 1850.0 - 1910.0 MHz 0.224 W 1850.0 - 1910.0 MHz 0.224 W 1850.0 - 1910.0 MHz 0.219 W 1850.0 - 1910.0 MHz 0.217 W 824.0 - 849.0 MHz 0.228 W... -
Page 50: Lte E362 Wwan Frequency Requirements
FCC Radio information bintec elmeg GmbH C.4 LTE E362 WWAN Frequency Requirements The device complies with the relevant sections of the FCC rules: • FCC CFR47 Part 24 (Narrow and wideband PCS modules) • FCC CFR47 Part 22 (Cellular Service) •... -
Page 51: Antenna Requirements
FCC Radio information bintec elmeg GmbH 824.7 - 848.3 MHz 0.222 W 824.7 - 848.3 MHz 0.219 W 1852.4 - 1907.3 MHz 0.208 W 1850.7 - 1909.3 MHz 0.243 W 1850.7 - 1909.3 MHz 0..24 W 1850.7 - 1903.3 MHz 0.202 W... - Page 52 FCC Radio information bintec elmeg GmbH 2500 MHz 9 dB Wi-Fi 2.4 GHz 2 dB Wi-Fi 5 GHz 2 dB bintec H2 Automotive+...
