    1 About This Guide bintec elmeg Chapter 1 About This Guide This is the installation guide for the bintec 4Ge-LE router. It contains information on how to correctly install this device in a working environment. 1.1 Supported Devices The information included in this installation guide only applies to the bintec 4Ge-LE router.
  • Page 7 1 About This Guide bintec elmeg Fax: +49 - 911 - 688 0725 Email: support@bintec-elmeg.com bintec 4Ge-LE...
  • Page 8: Chapter 2 Bintec 4Ge-Le

    11. 2.1.2 Hardware Monitoring The bintec 4Ge-LE router hardware is monitored through the LEDs panel, which provides visual information on what is happening in the device. The LEDs indicate the state of the hardware components, if there is connectivity, data flow, etc.
  • Page 9: Chapter 3 Components And Power Supply

    Front panel elements table Item Description WWAN antenna for the bintec 4Ge-LE. Slot for the SIM card. 3.1.2 Rear Panel The following figure shows the rear panel. Here you can see all the connectors for the bintec 4Ge-LE. bintec 4Ge-LE...
  • Page 10: Side Panels

    Two WWAN antennas are located on the side panels, one on either side. Right hand side panel Left hand side panel Fig. 3: and Fig. 4: 3.1.4 Underside Panel The following elements can be found on the underside panel: bintec 4Ge-LE...
  • Page 11: Top Panel (Leds)

    Perforations to install a DIN rail mount. (Optional.) 3.1.5 Top Panel (LEDs) The LEDs panel provides information on the state of the components (whether they are active or not) and on the net- work activity. LEDs Panel Fig. 5: bintec 4Ge-LE...
  • Page 12: Assembly

    3 Components and Power Supply bintec elmeg The LEDs for the bintec 4Ge-LE are shown in Figure 6. The table below contains a description of them: LEDs table Status Description Tricolor Green -> connected. Blinking: con- nection data activity. Amber -> blinking: auto-test.
  • Page 13 The screws must go into a wall stud (wood) or a wall anchor of the appropriate type for the wall. Screws into drywall are not strong enough to mount the router. Wall-mounting features Fig. 8: The above figure shows the wall-mounting features on the bintec 4Ge-LE. Wall screws 8.8 cm (3.46 inches) Chassis mounting holes (on...
  • Page 14: Ceiling Mounting

    - The accessories must be properly adapted to the kind of wall in place and must be chosen to ensure that they can support the weight of the device. 3.2.4 Ceiling mounting To attach the bintec 4Ge-LE device to the ceiling, use the appropriate support (not included and must be ordered separately). Ceiling mounting support Fig.
  • Page 15: Power Source

    DIN rail mount adapter Fig. 10: 3.3 Power Source The bintec 4Ge-LE is powered though an external AC/DC source or through an Ethernet cable (if it complies with the POE 802.3af standard). Warning The equipment must be used with the power supply provided by the manufacturer.
  • Page 16: Poe

    Diagram to connect the PoE adapter to the router Fig. 11: The bintec 4Ge-LE device can be powered through an Ethernet cable if the latter complies with the POE 802.3aF standard. The ETHERNET port is enabled for this. To connect the Ethernet cable with PoE power to the router, please carry out the steps outlined in...
  • Page 17: Disconnect

    • Router: If you have a router license, the device will behave as a router. In this case, the default configuration estab- lishes the following access IP address and the mask: IP address: 192.168.1.1 IP mask: 255.255.255.0 • 4Ge: If you have a 4Ge license, the device will have a special configuration. Please see manual bintec Dm592-I - bintec 4Ge-LE...
  • Page 18: Connecting Data

    Cell (located on the front panel of the router). The installation of these antennas in the bintec 4Ge-LE is essential to improve the quality of the signal received and transmitted by the cellular model.
  • Page 19: Installing The Sim Card

    3.6 Installing the SIM card A SIM card needs to be inserted in the bintec 4Ge-LE so the WWAN interface operates correctly. The router is equipped with an external tray for SIM cards. When inserting the SIM card, make sure you are protected against electrostatic discharges (ESD).
  • Page 20 • Place the router as shown in the figure above. • To insert the SIM card, follow the instructions shown on the bintec 4Ge-LE. • Press it until it is fully inserted. • To extract it, press it again and remove it.
  • Page 21: Chapter 4 Compliance

    4 Compliance bintec elmeg Chapter 4 Compliance 4.1 Manufacturer Information Teldat Brand Manufacturer Teldat S.A. Country Spain Postal Address Isaac Newton, 10 Parque Tecnológico de Madrid, 28760 Tres Cantos, Madrid, Spain International Phone +34 91 807 65 65 bintec 4Ge-LE...
  • Page 22: Safety Warnings

    4 Compliance bintec elmeg 4.2 Safety Warnings Connect Disconnect bintec 4Ge-LE...
  • Page 23 4 Compliance bintec elmeg bintec 4Ge-LE...
  • Page 24 4 Compliance bintec elmeg bintec 4Ge-LE...
  • Page 25: Weee Information

    4.5 EC Declaration of Conformity English (EN) Hereby, bintec elmeg declares that the bintec 4Ge-LE radio equipment is in com- pliance with: Directive 1999/5/EC (until 12 June 2017) and Directive 2014/53/EU (from 13 June 2017)
  • Page 26: National Restrictions

    In accordance with article 10 of Directive 2014/53/EU, we inform you that there may be national restrictions and re- quirements for authorization. Country requirements may evolve with time. bintec elmeg recommends that you check with local authorities for the latest status of their national regulations.
  • Page 27 This device and its antennas(s) must not be placed or operated in conjunction with any other antenna or transmitter, except when done in accordance with IC multi-transmitter product procedures. Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur. bintec 4Ge-LE...
  • Page 28: Appendix A Technical Information

    A.2 Updating the software The bintec 4Ge-LE can be updated to new releases. Please contact your distributor for further details on new re- leases. Firmware updating is carried out through a traditional FTP file transfer. For further information on updating firmware through FTP, please see manual bintec-Dm748-I Software Updating, section 1.3 FTP Updating.
  • Page 29: Lan Connector

    A.3.2 WWAN Connector (female) Internal RF in/out External A.3.3 Power Supply Connector Internal POSITIVE External NEGATIVE A.4 Technical Specifications A.4.1 Hardware Architecture PROCESSORS Freescale P1014. MEMORY DDR3 1Gbit (128 MBytes). STORAGE UNIT FLASH Memory 128 Mbits (16 Mbytes). bintec 4Ge-LE...
  • Page 30: Lan Interface

    A.4.5 External Power Supply INPUT VOLTAGE 100-240 V AC. INPUT CURRENT 1.0 A. INPUT FREQUENCY 50-60 Hz. A.4.6 Dimensions and weight TYPE Desktop or wall-mounted. LENGTH x WIDTH x HEIGHT 145 x 160 x 50 mm. WEIGHT 0.3 kg. bintec 4Ge-LE...
  • Page 31: Environmental Specifications

    Technical Information bintec elmeg A.4.7 Environmental Specifications TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC STORED: -25 ºC to 70 ºC RELATIVE HUMIDITY On: 5 % to 90 % bintec 4Ge-LE...
  • Page 32: Appendix B Radio Information

    Band 7 (2600) Tx: 2500–2570 MHz Class 3, 23 dBm max. Band 20 (800) Tx: 832–862 MHz Class 3, 23 dBm max. This product is supplied with YWX-6221SAX9-508 antennas. To comply with the regulations, do not choose others. bintec 4Ge-LE...
