- Page 1 Manual bintec elmeg RXM7000 Installation Manual Copyright© bintec Dm667-I Version 1.1 5/2017 bintec elmeg RXM7000...
- Page 2 This publication is subject to change. bintec elmeg offers no warranty whatsoever for information contained in this manual. bintec elmeg is not liable for any direct, indirect, collateral, consequential or any other damage connected to the de- livery, supply or use of this manual.
-
Page 3: Table Of Contents
RXM7000 ........4... - Page 4 Table of Contents bintec elmeg 3.7.3 Connecting a 3G USB device (USB connector) ..... . 3.7.4 Connecting for Configuration ......
-
Page 5: I Related Documents
Related Documents bintec elmeg I Related Documents bintec Dm748-I Software Updating RXM7000... -
Page 6: Chapter 1 About This Guide
1 About This Guide bintec elmeg Chapter 1 About This Guide This installation guide for the RXM7000 router contains information on how to correctly install this device in a working environment. 1.1 Supported Devices The information provided in this installation guide only applies to the RXM7000 router. - Page 7 1 About This Guide bintec elmeg Fax: +49 - 911 - 688 0725 Email: support@bintec-elmeg.com RXM7000...
-
Page 8: Chapter 2 Rxm7000
2.1.2 Hardware Monitoring The LEDs on the front panel are used to monitor the hardware in the RXM7000 router. These LEDs provide visual in- formation on the state of the device and reference the condition of the hardware components, indicating whether there is connectivity, data flow, etc. -
Page 9: Chapter 3 Components And Power Supply
3 Components and Power Supply bintec elmeg Chapter 3 Components and Power Supply The following chapter provides detailed information on the chassis of the RXM7000 router and its components. This information includes: • Components. • Information on assembly. • Installing and uninstalling modules. - Page 10 3 Components and Power Supply bintec elmeg Red -> Interface unavailable because it is installing, disabled (shutdown) or due to auto-test failure. Amber -> Idle. • Rapid blinking. It has not registered in the network or the quality is insufficient.
-
Page 11: Rear Panel
Green -> Link detected. Blinking: con- nection data activity. 3.1.2 Rear Panel The following figure shows the rear panel. Here you will find the majority of the RXM7000 router connectors. Rear panel Fig. 3: The following table provides information on each connector, as well as a description:... -
Page 12: Expansion Slots
On/Off switch. 3.2 Expansion Slots The RXM7000 router has two expansion slots. This allows you to increase the features and interfaces by inserting different cards or boards. These slots are located on the router's front panel, as shown in the following figure: Expansion slots Fig. -
Page 13: Installation In A Rack
3.3 Installation in a rack The RXM7000 device can be installed in a 19” rack. The necessary strips and screws are not provided by default and have to be acquired separately. (1) First, the maroon side tabs must be removed to free the screws holes:... -
Page 14: Standalone
Fig. 10: 3.3.1 Standalone RXM7000 devices can be placed as standalones on a flat, stable surface. The adhesive rubber feet must be stuck to the underside panel to prevent the router from sliding. Make sure there is enough space around the router (for ventilation purposes) and check that the power cord and data cables can reach it. -
Page 15: Plug-In Modules
The RXM7000 router is powered through an internal AC/DC source. The RXM7000 may also incorporate a card to inject PoE through the 4 ports of the 8-port Switch. In this case, an ex- ternal adapter is needed to provide power to PoE module. -
Page 16: Poe Source
• Disconnect the data cables. 3.5.2 PoE Source The RXM7000 can be powered through an Ethernet cable that complies with the PoE 802.3af standard (15.4 W per port). This feature needs an external adapter and internal card to work. The following figure shows where to connect the PoE source to the device: PoE source connection (blue) and PoE ports (red) Fig. - Page 17 3 Components and Power Supply bintec elmeg MiniPoE card Fig. 14: : Location (6) Place the MiniPoE card so that it matches the three connectors. This operation must be carried out carefully, without forcing any piece or part of the device. Check that the card is clearly settled over the connectors.
-
Page 18: Rst Button
3 Components and Power Supply bintec elmeg PCI device: PowerPC processor, RC (Bus: 0, Device: 0, Function: 0) (Vendor: 0x1957, Device: 0x0840) (Subs. Vendor: 0x0000, Subs. Device: 0x0000) SLOT1 - PCI device: Ethernet controller (Bus: 1, Device: 0, Function: 0) (Vendor: 0x8086, Device: 0x1537) (Subs. -
Page 19: Rebooting The Device
During booting and in BIOS mode, only the LAN 1 connector is available. 3.7.2 WAN Connection The RXM7000 has one Ethernet interface for WAN connection. This port has two connectors - SFP for optical link and RJ45 for 10/100/1000 Base-T link - but they cannot work simultaneously. This interface is totally independent from the switch and is handled as just one more interface. -
Page 20: Connecting A 3G Usb Device (Usb Connector)
During booting and in BIOS mode, the WAN connectors do not work. 3.7.3 Connecting a 3G USB device (USB connector) The RXM7000 router has a USB HOST 2.0 Type A connector interface. It allows 3G USB modems to be connected. The interface can be activated by purchasing the corresponding software license. - Page 21 3 Components and Power Supply bintec elmeg Unscrewing the screws from the front panel tray Fig. 22: (4) Once unscrewed, pull out the tray from the front panel slot. Extracting the tray from the front panel Fig. 23: (5) If the tray is attached, skip to the next step. Otherwise, once you have extracted the tray, place the hard disk in the correct position.
-
Page 22: Procedure To Install A Flash Memory Expansion Sd
3 Components and Power Supply bintec elmeg Inserting the hard disk Fig. 25: (7) Screw the tray to the device. Screw the tray to the front panel Fig. 26: (8) Connect the equipment as indicated in section 3.5.1.1 "Connecting". Connect the terminal to the console and check that the device detects the hard disk. - Page 23 3 Components and Power Supply bintec elmeg Inserting SD card Fig. 27: RXM7000...
-
Page 24: Chapter 4 Compliance
4 Compliance bintec elmeg Chapter 4 Compliance 4.1 Manufacturer Information Brand bintec Manufacturer bintec elmeg Country Germany Postal Address Suedwestpark 94 90449 Nuremberg Germany International Phone +49 - 911 - 9673 0 RXM7000... -
Page 25: Safety Warnings
4 Compliance bintec elmeg 4.2 Safety Warnings Connecting Discon- necting RXM7000... -
Page 26: Weee Information
Directive 2009/125/EC (ErP) Directive 2011/65/EU (RoHS) of the European Parliament and of the Council. Spanish (ES) Español Por la presente, bintec elmeg declara que el tipo de equipo radioeléctrico RXM7000 es conforme con: Directiva 2014/30/UE (EMC) Directiva 2014/35/UE (LVD) Directiva 2009/125/CE (ErP) Directiva 2011/65/UE (RoHS) del Parlamento Europeo y del Consejo. -
Page 27: Laser Product
4 Compliance bintec elmeg 4.6 Laser Product Use only trained and qualified personnel to install or replace this device Chose SFP+ transceivers that meet the following regulations • Class 1 • Application of CE marking in accordance with the2014/30/EU EMC Directive and the 2014/35/EU Low Voltage Directives •... -
Page 28: Appendix A Technical Information
A.3 Connecting to the device A.3.1 Connecting using the local console (Aux connector) The RXM7000 router has a RJ45 female connector on the front panel ( Aux.), which provides access to the device's local console. Aux Connector Fig. 30: To configure this, connect the Aux. -
Page 29: Connectors
Technical Information bintec elmeg Note The configuration for the terminal must be: - Speed: 9600 bps. - Eight data bits. - One stop bit. - No parity bit. - No type of flow control. Connection to the configuration port is done through the the RJ45 connector cable, supplied with the device, and an RJ45 female-DB9 female adaptor (also provided). -
Page 30: Wan Base-T Connector
Technical Information bintec elmeg A.4.2 WAN Base-T Connector RJ45 WAN RJ45 PIN FE Signals GE Signals BI-DA+ BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.4.3 WAN SFP Connector Standard SFP connector A.4.4 USB Connector USB Type A... -
Page 31: Configuration Connector
Technical Information bintec elmeg A.4.5 Configuration Connector RJ45 CONFIGURATION RJ45 PIN CONF A.5 Technical Specifications A.5.1 Hardware Architecture PROCESSORS Freescale QorIQ. MEMORY 1 Gbyte in SDRAM. STORAGE UNIT FLASH Memory (32 Mbytes). A.5.2 LAN Interface PROTOCOLS Ethernet (802.3). PORTS 8-port switch managed with MDI/MDX auto-detection. -
Page 32: Wan Sfp Interface
Technical Information bintec elmeg A.5.4 WAN SFP Interface STANDARDS 802.1Q (VLAN). 1000-Base-X. SPEED 1000 Mbps full duplex. TYPES LX/LH (single-mode 1310 nm). SX (multi-mode 850 nm). ZX (single-mode 1550 nm). CONNECTOR Standard SFP connector. A.5.5 USB Interface 3G USB MODEMS Please visit the bintec website http://www.bintec-elmeg.com for a list of supported... -
Page 33: Environmental Specifications
Technical Information bintec elmeg A.5.9 Environmental Specifications TEMPERATURE OPERATING NORMALLY: 0 ºC to 40 ºC. STORED: -25 ºC to 70 ºC. RELATIVE HUMIDITY On: 5 % to 90 %. RXM7000...
