- Page 1 Manual bintec elmeg RM3000 Router Installation Manual Copyright© bintec Dm569-I Version 8.5 07/2018 bintec elmeg RM3000 Router...
- Page 2 This publication is subject to change. bintec elmeg offers no warranty whatsoever for information contained in this manual. bintec elmeg is not liable for any direct, indirect, collateral, consequential or any other damage connected to the de- livery, supply or use of this manual.
-
Page 3: Table Of Contents
Chapter 2 RM3000 Devices ........4 Characteristics ........ - Page 4 USB Connector........A.5.6 Configuration Connector ....... . RM3000 Router...
- Page 5 WWAN Specifications ....... . . WIFI Specifications ........RM3000 Router...
-
Page 6: I Related Documents
Related Documents bintec elmeg I Related Documents bintec Dm748-I Software Updating RM3000 Router... -
Page 7: Chapter 1 About This Guide
1 About This Guide bintec elmeg Chapter 1 About This Guide This installation guide for the bintec RM3000 router family contains information on how to correctly install the device in a working environment. 1.1 Supported Devices The information provided in this installation guide only applies to the bintec RM3000 router family. - Page 8 1 About This Guide bintec elmeg Tel. no.: +49 - 911 - 9673 0 Fax: +49 - 911 - 688 0725 Email: support@bintec-elmeg.com RM3000 Router...
-
Page 9: Chapter 2 Rm3000 Devices
2.1.2 Hardware Monitoring The only way to monitor the bintec RM3000 router family hardware is through the LEDs on the front panel. The LEDs provide visual information on the state of the device. They indicate the condition of the hardware components, if there is connectivity, data flow, etc. -
Page 10: Chapter 3 Components And Power Supply
3 Components and Power Supply bintec elmeg Chapter 3 Components and Power Supply The following chapter provides detailed information on the chassis of the bintec RM3000 router family and its com- ponents. This information includes: • Components. • Information on assembly. -
Page 11: Rear Panel
Level from 0 (all the LEDs off) to 4 (all lit up). (1, 2, 3, 4) 3.1.2 Rear Panel The following figure shows the rear panel. Here you will find the majority of the bintec RM3000 router family con- nectors. RM3000 Router... -
Page 12: Side Panels
Left hand side panel Fig. 3: and Fig. 4: The connectors are as follows: Side panel connectors Item Description Wi-Fi antenna connectors. 3G antenna connectors. 3.1.4 Underside Panel The following elements can be found on the underside panel: RM3000 Router... -
Page 13: Expansion Slot
Adhesive rubber feet (these are not required if mounted in a rack). 3.2 Expansion Slot The bintec RM3000 router family has an expansion slot, which means you can increase its features and interfaces by inserting different cards or boards. This slot is located on the router’s front panel, as shown in Figure 6: Expansion slot Fig. - Page 14 Please see Fig. 8 on page 9. Placing the expansion card Fig. 8: (6) Finally, insert the tray into the device once again using the appropriate guides. See Fig. 9 on page 10. RM3000 Router...
-
Page 15: Installation In A Rack
(8) Connect a terminal to the console and check that the device detects the expansion card. 3.3 Installation in a rack The bintec RM3000 device family can be installed in a 19” rack. The strips and screws needed are not provided by default and need to be acquired separately. -
Page 16: Wall Mounting
3.3.2 Wall mounting The bintec RM3000 can be mounted on the wall. This optional kit can be ordered separately or together with the bintec RM3000. The anchors to mount the device on the wall must be installed as shown in the following figure, using the screws provided by the manufacturer. -
Page 17: Plug-In Modules
Fig. 13 on page 12. 3.5 Power Source The bintec RM3000 router family is powered though an external AC/DC source. Workplace conditions. Main characteristics • Avoid humid and or dusty locations. • Direct exposure to sunlight, as well as other heat sources, should be avoided. The device should not be placed amongst papers, magazines or other elements that could hinder natural air circulation. -
Page 18: Connecting
Some devices leave the factory with customized settings. This personalization may mean that the de- fault configuration is different from the one shown above. 3.7 Connecting the data The bintec RM3000 router family has the following data connections. RM3000 Router... -
Page 19: 4-Port Ethernet Switch
Cell connectors (located on the side panels of the router). Installing these antennas in the bintec RM3000 router is essential in order to improve the quality of the signal re- ceived and transmitted by the cellular model. - Page 20 The router must have the corresponding software license installed for the cellular interface to work. Some cellular telephony technologies use the antenna diversity technique to improve the quality of the signal re- ceived (HSUPA, CDMA EV-DO, etc.). Due to this, the bintec RM3000 router family is equipped with several WWAN connectors:...
-
Page 21: Wireless Lan Antenna Connection (Wi-Fi Connectors)
3G USB Connector Fig. 21: 3.7.6 Connecting for Configuration The bintec RM3000 router has an RJ45 female connector on the front panel known as “ Aux .” , which provides ac- cess to the device's local console. For further information, please see Connecting to the device on page 27. -
Page 22: Installing The Sim Card
3.8 Installing the SIM card The bintec RM3000 family has a Wireless WAN interface that, in order to operate, may require a SIM card to be in- serted into the device. Certain services (CDMA) provided by several carriers in some countries do not require SIM cards. - Page 23 (4) Return the tray to its original position. (5) While pressing on the tray, push the fastening towards the direction indicated by the word LOCK until it is firmly in place. Inserting the SIM in the internal tray Fig. 26: RM3000 Router...
-
Page 24: Chapter 4 Compliance
4 Compliance bintec elmeg Chapter 4 Compliance 4.1 Manufacturer Information Brand bintec Manufacturer bintec elmeg Country Germany Postal Address Suedwestpark 94 90449 Nuremberg Germany International Phone +49 - 911 - 9673 0 4.2 Safety Warnings RM3000 Router... - Page 25 4 Compliance bintec elmeg Connecting Disconnecting RM3000 Router...
- Page 26 4 Compliance bintec elmeg RM3000 Router...
- Page 27 4 Compliance bintec elmeg RM3000 Router...
-
Page 28: Weee Information
Proposition 65 requires the provision of a warning to California consumers regarding products contain- ing certain chemicals: WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. RM3000 Router... -
Page 29: Ec Declaration Of Conformity
Directiva 2014/35/UE (LVD) Directiva 2009/125/CE (ErP) Directiva 2011/65/UE (RoHS) del parlamento Europeo. The EC declaration of conformity and additional product documentation can be accessed here: http://www.bintec-elmeg.com/conformity 4.6 CE Marking This equipment is in conformity with the CE procedures and marking. RM3000 Router... -
Page 30: National Restrictions
In accordance to article 10 of 2014/53/EU, we inform you that there may be national restrictions and requirements for authorization. The requirements for any country may evolve. bintec elmeg recommends that you check with local au- thorities for the latest status of their national regulations. -
Page 31: Ic Statement
This device and its antennas(s) must not be co-located or operating in conjunction with any other antenna or trans- mitter except in accordance with IC multi-transmitter product procedures. Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur. RM3000 Router... -
Page 32: Appendix A Technical Information
A.3 Connecting to the device A.3.1 Connecting using the local console (Aux connector) The bintec RM3000 router has an RJ45 female connector on the front panel known as “ Aux .” , which provides ac- cess to the device local console. -
Page 33: Licenses
Fig. 29: A.4 Licenses The bintec RM3000 router family offers a series of licenses among which the following stand out: WiFi: Activation license for the WLAN 802.11bgn. USB: Activation license for the USB port to be used for the WWAN modems. -
Page 34: Lan Connector
BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.5.2 WAN Connector RJ45 WAN RJ45 PIN FE Signals GE Signals BI-DA+ BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.5.3 WWAN Connector (female) Internal RF in/out External RM3000 Router... -
Page 35: Wlan Connector (Male)
A.5.4 WLAN Connector (male) Internal RF in/out External A.5.5 USB Connector USB Type A DATA- DATA+ Shell Shield A.5.6 Configuration Connector RJ45 CONFIGURATION RJ45 PIN CONF A.5.7 Power Supply Connector Internal POSITIVE External NEGATIVE A.6 Technical Specifications RM3000 Router... -
Page 36: Hardware Architecture
Depends on the type of Wireless WAN module. Please see the antenna catalog for Cellular interfaces. A.6.5 Wireless LAN Interface STANDARDS 802.11abgn. FREQUENCY 2.4 GHz / 5 GHz. SPEED Depends on the Wireless LAN module. CONECTOR Up to 3 RF RP-SMA female. RM3000 Router... -
Page 37: Usb Interface
LENGTH x WIDTH x HEIGHT 245 x 210 x 45 mm. WEIGHT 1.4 kg. A.6.11 Environmental Specifications TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC STORED: -25 ºC to 70 ºC RELATIVE HUMIDITY On: 5 % to 90 % RM3000 Router... -
Page 38: Radio Information
Tx: 5150-5350 MHz 23 dBm max. 5 GHz with TPC * Tx: 5470-5725 MHz 30 dBm max. 5 GHz without TPC * Tx: 5150-5250 MHz 23 dBm max. 5 GHz without TPC * Tx: 5250-5350 MHz 20 dBm max. RM3000 Router... - Page 39 Radio Information bintec elmeg 5 GHz without TPC * Tx: 5470-5725 MHz 27 dBm max. * TPC: Transmit Power Control This product is supplied with antennas EDA-8709-25GR2-A9. To comply with the regulations, do not choose other antennas. RM3000 Router...
