Device Manager

Color coded Information

Color coding for lists in tabs
• If the version number is shown in red, the Device Manager has found no parameter definition
files supporting that device type.
• If the version number is shown in dark red, the parameter definition file is compatible, but
does not have exactly the same version as the device.
Color coding for parameter and template editing
In the parameter and template editing windows, the following color coding is used:
color Context
Black General
Dark For templates and parameter editing
blue
Purple For templates
Red For templates and parameter editing
Turqoise For templates and parameter editing

Navigation

For keyboard short-cuts, see

Tabs

The Device manager has different views, or tabs:
• Devices tab
• Numbers tab
• Templates tab
• Licenses tab
Each tab shows information about devices, Numbers, templates, or licenses. Some information
overlaps, for example Device ID, which is tied to both a specific device and to a specific Number.
Different menus are accessible in the different tabs.
Devices Tab
The Devices tab shows all devices configured at the site in a detailed list. The following columns
are displayed:
• Description – .optional information of a Number that can be added by the user. For example,
the location of the device.
• Device ID – the unique identifier of the device.
• Device type – the device model.
• Software version – shows the version of the software in the device.
• Parameter version – shows the version of the parameters in the Number.
• Upgrade status – might show one of the symbols shown in table below.
38
Used IP Ports on page 96.
A31003-M2000-M105-01-76A9, 29/06/2020
Wireless Service Gateway WSG, Administrator Documentation
Description
Normal
Parameter has been edited during the
current session
The parameter is included in the tem-
plate (checked)
Value not valid
The value differs from the default value
