Layout

Input LEDs
Switch
IR port
Power plug
HDM output
Figure 1: 3-Port HDMI Switcher 4K - Black
• Input LEDs: On when input signals are detected
• Switch: Select input source 1, 2, or 3
• HDMI output: Connects to an HDMI display or TV
• Power plug: Connects to the included power cable
• IR port: Plug IR receiver extension cable here
HDMI inputs
Figure 2: 3-Port HDMI Switcher 4K - Black
• HDMI inputs: Connect to HDMI source devices
