4x1 HDMI 2.0 Switch with
HDMI ARC & CEC
User's Guide
P/N: Switch41-HD20
G4-0094A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Switch41-HD20 and is the answer not in the manual?

Questions and answers

Summary of Contents for gofanco Switch41-HD20

  • Page 1 4x1 HDMI 2.0 Switch with HDMI ARC & CEC User's Guide P/N: Switch41-HD20 G4-0094A...
  • Page 2 Thank you for purchasing from gofanco. Our products aim to meet all your connectivity needs wherever you go. For optimum performance and safety, please read the instructions carefully and keep this User’s Guide for future reference. If you need more information about our products, please visit www.gofanco.com.
  • Page 3 • Shut off power and make sure environment is safe before installation • Do not plug the HDMI cables in/out when the device is in use to avoid cable damage. Make sure they are plugged into the correct ports • Use the included DC5V power adapter only.
  • Page 4 Package Contents • 4x1 HDMI 2.0 Switch with HDMI ARC & • Remote controller • RS232 cable (3.5mm to DB9) • 2 Mounting ears + 4 mounting screws • IR Receiver cable • 4 Plastic pads • Power adapter • User's guide Installation Requirements HDMI source device (computer, DVD...
  • Page 5 Layout Figure 1: Front Panel Layout Figure 2: Rear Panel Layout...
  • Page 6 Hardware Installation Power off all devices including your HDMI source and HDMI display(s). Connect your HDMI source devices to the Switch's HDMI Input connectors with HDMI cables (HDMI cables not included). Connect your HDMI display to the Switch's HDMI ouput connector with an HDMI cable (HDMI cable not included).
  • Page 7 Connection Diagram The diagram shows the moset typical input and output devices used with the switch.
  • Page 8 Auto/Source Button Control Manual Switching When manual switching mode is enabled, the switching mode LED will be green. Simply press the Auto/Source button to switch to the next input device. Automatic Switching To enable automatic switching mode, press and hold down the Auto/Source button for 3 seconds. The switching mode LED will turn to yellow color.
  • Page 9: Remote Controller

    Remote Controller Figure 3: Remote Controller...
  • Page 10 RS232 Control Software Works with most serial command and monitoring software such as CommWatch. • Download CommWatch or the serial command software of your choice • Installation: Copy the control software files and paste them to the hard drive of your PC •...
  • Page 11 Control Software Interface Set the COM port, Baud rate, data bit, stop bit, and parity. Enter commands into the Command Sending Area. RS232 Commands Default settings: Baud rate: 9600, Data bit: 8, Stop bit: 1, Parity bit: none. Notes • In Commands column, "["and"]"...
  • Page 12 Signal Switching Source Device Control • The input source device must support CEC • HDMI Input 4 doesn't support CEC IR Remote control commands...
  • Page 13 Source Device Control Continued Display Device Control...
  • Page 14 Audio Selection System Control...
  • Page 15 EDID Management Embedded EDID Settings The 4-pin DIP switch controls the embedded EDID settings.
  • Page 16 FAQ & Solutions There is no video output or audio and video display is not normal. 1) Check the power adapter connection and make sure the Switch's Power LED is on. 2) Check whether the HDMI cables are connected properly. 3) Check the TV is set to the correct HDMI input.
  • Page 17: Specifications

    Specifications...
  • Page 18 Blank Page...
  • Page 19 Disclaimer The product name and brand name may be registered trademarks of related manufacturers. TM and ® may be omitted on the user’s guide. The pictures on the user’s guide are just for reference, and there may be some slight differences with the actual products.
