An open track configuration utilizes an End of Track Bumper on each track end to ensure the trolley is
safely stopped. The power rail is attached to the overhead mechanical track and delivers electricity to
the Vector Elite trolley.

Power Supply Box

The power supply box is mounted to a wall and plugs into a dedicated electrical outlet. It converts
electrical power from the building to a predetermined power level, which is supplied to the trolley through
the power rail. The power supply box also contains an electrical isolation transformer, as a safety feature
of the system.

Vector Elite Trolley

The Vector Elite trolley consists of two motors and a rope that attaches to the spreader bar. A computer-
controlled motor keeps the trolley at a desired location relative to the patient, and a separate computer-
controlled motor ensures that the rope tension is kept at a desired value.

Spreader Bar

The spreader bar connects a patient harness to the Support Rope at two points. On each side of the
spreader bar there are three holes built to accommodate patients of different sizes.

Patient Harness

The patient harness secures a patient during a therapy session. The patient harness comes in a variety
of different sizes and attaches to the spreader bar.
PC
The touch-screen PC contains the software that controls the Vector Elite system and manages the secure
patient database. The Vector Gait & Safety System software is password-protected and communicates
with the trolley through an encrypted WiFi signal.

Remote Control

The optional remote control may be used to control the System once a training session has begun. This
accessory is not necessary to operate the Vector Elite system. The remote control uses an Android
operating system with a Vector Gait & Safety System application and communicates with the trolley
through an encrypted WiFi signal.
Be sure to review this guide, including all safety information, before using the Vector Elite system. If you
have questions contact Bioness at 800.211.9136, Option 3 (in the United States) or your local distributor
(outside of the United States). You can also visit the Bioness website at: www.bioness.com.
Caution: Do not use the Vector Elite system until you have been properly trained by a Bioness
representative.
