Technical Specifications
Vector Elite System Technical Specifications
Trolley dimensions
Trolley material
Trolley patient weight limit
Support Rope material
Spreader bar material
Environmental conditions for operation
Environmental conditions for transport and
storage
Electrical requirements for single trolley
configured system
Electrical requirements for multi-trolley
configured system
The system consists of mechanical and electronic components. Inadequate handling of those components
may cause health hazards. Disposal of the system must comply with local regulations.
36 inches (91.4 cm) long, 25 inches (63.5 cm)
wide, and 11 inches (27.9 cm) tall
Cover is ABS V0 plastic, base is aluminum grade
60601-T6
500 lbs. (227 kgs.)
8 mm diameter HMPE (high modulus
polyethylene)
Anodized aluminum
Temperature range: 15C to 35C
Atmospheric pressure range: up to 80kPa
Relative humidity range: 20% to 60%.
Temperature range: -25C to 70C
Atmospheric pressure range: up to 67kPa
Relative humidity range: 5% to 95%
110/120VAC, 20A, 50/60Hz or 220/240VAC, 10A
50/60Hz dedicated circuit
Outlet must be capable of delivering 1.8kW
210/240VAC, 20A, 50/60Hz dedicated circuit
Outlet must be capable of delivering 3.0kW
