Bioness GO L300 Clinician's Reference Card

Clinician's Reference Card

Component Pairing

IMPORTANT: Pair system components before pairing to Clinician Application
Thigh FS Cuff with Lower FS Cuff.
1
EPG Pairing Mode Activation: Simultaneously press
on the Plus and Minus button on each EPG. EPG status
indicator light will flash Green, Yellow, Red.
If needed, pair the Foot Sensor to the Lower FS Cuff EPG.
2
Foot Sensor Pairing Mode Activation: Pair the Foot
Sensor to a new EPG by placing a battery (CR2032) into
the Foot Sensor and pressing on the pressure sensor,
green light will blink to confirm pairing mode activation.
Place the lower EPG in pairing mode.

Pairing System to Clinician Application

Log into L300 Go Clinician Application
1
Select to access the linking screen. Place System
2
into Pairing Mode by simultaneously pressing plus and
minus button on EPG. Select
desired leg. Once paired, exit linking screen by clicking
on
Select a patient i.e. Work with Existing patient, Create
3
New or Choose from List.
If selecting from the Patient List, press the
Upload icon or double click the chosen name.

Fitting the L300 Go System

Attach the personal panel.
1
Slide the personal strap cover over the Cuff strap.
2
Wipe the stimulation area with a damp, soft cloth. Then, slightly extend the lower leg.
3
Once the electrode(s) are attached to the L300 FS Cuff, place the cuff on the leg using the cuff
4
patella locator, secure strap, adjust tension.
Program stimulation settings to achieve desired response.
5
1
L300 Go , Bioness, the Bioness Logo
®
612-00851-001 Rev. D
Link icon above
2
and LiveOn are trademarks of Bioness Inc. | www.bioness.com
® ®
