EN

Direct connection

Current (I
, I , I , I , I )
st min tr ref max
0.02 A / 0.25 A / 0.5 A / 5 A / 75 A (5(75))

Current transformer /5A und /1A

Current /5A (I
, I , I , I , I
st min tr ref max
0.01 A / 0.05 A / 0.25 A / 5 A / 6 A (5(6))
Current /1A (I
, I , I I , I
st min tr, ref max
0.002 A / 0.01 A / 0.05 A / 1 A / 1.2 A (1(1.2))

Installation instruction

Torque
Connection
Flexible wire
Input lead L1/L2/L3
Neutral conductor
S0 pulse output 0,4 Nm (max. 2.5mm
Tariff control 0,4 Nm (max. 2.5mm
12
)
)
Direct Current
max. 35mm 2 transformer max.
strand 6mm strand
2
2-3 Nm 1.3 - 1.6 Nm
2-3 Nm 1.3 - 1.6 Nm
strand)
2
strand)
2
Cable requirement >65A
Type: Wire (Cu), cross-section: 35mm²,
Outside-Ø 9,55 mm

DISPLAY LANGUAGE

Display language can be selected between English and German
(Deutsch).

Configure of display language

For all device variants:
After connecting the voltage, the actual language will be shown
on the display for about 10 seconds.
With the multicount D5-3P -xxx- MID, the language can also be
changed in the settings:
1) Blue key to Adjustments
2) Red key to Language (Sprache)
3) Push Service-Key briefly
4) Adjust Language by blue key
5) Saving: Push Service key
for 5 seconds, until the display
stops to flash
