Current transformer /1A

YYYY : 1A
Y adjustable in steps of 1
Configuration of current transformer ratio
1) Blue key to Transformer ratio
2) Push service key briefly
3) Adjust secondary current by blue key
4) Go to primary current by red key
5) Adjust first two digits by blue key
6) Go to next digit by red key
7) Adjust digit by blue key
8) Go to next digit by red key.
9) Adjust next two digits by blue key.
10) Saving: Push Service key for 5 seconds, until digits are not blinking

S0 pulse-output

The four S0 pulse-outputs are designed according to EN62053-31
(DIN 83864). Pulse rate and pulse lengths can be configured by the
keys.
16

Default settings ex-factory

1. S0 Output = Active Energy Import (12+13)
2. S0 Output = Reactive Energy Import (10 + 11)
3. S0 Output = Active Energy Export
4. S0 Output = Reactive Energy Export (6 + 7)
Direct conn.
Pulse rate 1000 Imp./kWh
Pulse length 40ms
The multicount D5-3P-xxx-MID only has one pulse-output for active
energy import.

Configuration pulse rate

1) Blue key to Adjustments
2) Red key to S0 Pulse Rate
3) Push service key briefly
4) Move decimal place by blue key Example 1000.000 = 1000 Impulse
5) Saving: Push Service key for 5 seconds, until digits are not blinking
(8 + 9)
CT
10 Imp./kWh
120ms
