Configuration of pulse length
1) Blue key to Adjustments
2) Red key to S0 Pulse Duration
3) Push service key briefly
4) Adjust pulse length by blue key
5) Saving: Push Service key for 5 seconds, until digits are not blinking
S0 pulse-output
Opto Power MOSFET
5 – 230 VAC or VDC, max. 90mA
Rate per kWh / kvarh
0.001, 0.01, 0.1, 1, 10, 100, 1000, 10'000
Length
Adjustable from 4 to 250 milliseconds in steps of 2 ms.
18
PEAK-CONTROL / THRESHOLD
Threshold
The following values can be chooses as a threshold:
- Active Power
- Reactive power
- Current total
- Current per phase L1 / L2 / L3
Only one threshold can be defined for all 4 outputs. Only positive
values are detected.
Default settings ex-factory
Threshold: 5.000 kW
Status:
Not active
- Apparent power
