EN
DANGEROUS VOLTAGE
The applicable DIN/VDE regulations must be observed during
installation!
Connection to the mains, commissioning and operation of the device
may only be carried out by qualified personnel. Qualified personnel
as defined in the safety instructions in this user manual are personnel
with electrical engineering qualifications, knowledge of the national
accident prevention regulations and safety engineering standards as
well as of the installation, commissioning and operation of the device.
To prevent fire and electric shock, do not expose the device to rain or
moisture!
Before connecting the device to the power supply, check whether the
local power supply conditions comply with the specifications on the
device nameplate.
Incorrect connection may result in the destruction of the device!
When connecting the device, adhere to the information given in the
connection diagram (see "Connection diagram") and that the connec-
ting cables are not live. When wiring, always ensure that all cables used
are neither damaged nor faulty and observe correct polarity!
6
To ensure proper and safe operation of the device, ensure that it is
transported, stored, installed, assembled, and carefully operated and
maintained in accordance with the specifications.
If the device has any visible damage it is considered unfit for use and
must be disconnected from the power supply! Troubleshooting, repairs
and maintenance work may only be carried out at our plant or after
contacting our customer service team.
Unauthorized opening of the device will render your warranty null and
void. Correct functioning can no longer be guaranteed!
Opening the device may expose live parts. Do not operate open
devices under any circumstances!
All input and output cables of systems that are at risk from lightning
strikes must be fitted with lightning protection.
7
