Chapter 2
Buhler/Versatile 4WD 400+ Series SmarTrax Hydraulic Kit (P/N 117-0194-098)
TABLE 2.
8
Buhler/Versatile 4WD 305 - 400 & HHT 4WD 400 - 575 SmarTrax Installation Manual
Item Description
Hose - 11/16" ORFS (F) to 13/16" ORFS (F) 90°, 18"
Hose - 11/16" ORFS (F) to 11/16" ORFS (F) 90°, 16"
Hose - 11/16" ORFS (F) to 11/16" ORFS (F) 90°, 45"
Part Number
Qty
214-1000-617
1
214-1000-618
1
214-1000-619
1
