System Administration
For example, with system linetest on and the SMS2000 rebooted, the SMS2000
generates a broadcast to the subscriber Ethernet interface once per second. Installers
should check for a blinking LED on a Long Run or Home Run adapter if they do not have
diagnostic equipment.
For example, to cause a test print page to be sent to the configured LPR printer, use:

Defining Ports

To configure the type of addressing information used by the SMS2000 to identify unique
subscriber ports, use this command:
For example, to configure SMS2000 to ignore VLAN tags and focus exclusively on
SNMP information, which is useful in error situations where addressing information fails
when a subscriber is connected bymeans of an Expresso GS/MDU Chassis behind a
VLAN switch, type:

Setting and Deleting Static Ports

Use the set port command to specify port types for all ports, and to set a port or a range
of ports as static, dynamic, or disabled or to delete ports.
For static ports, this command can also configure an IP address, local route, and default
VLAN ID. When you configure a single static port, you can use an optional IP address
and subnet mask to automatically configure the interface and add a local route. If a subnet
mask is not specified, the default 255.255.255.255 is used.
TUT Systems, Inc
{left|right}}[help | ?]
sms2000% system linetest on
sms2000% system lprtest
Some of the system command options will disrupt elements of the
Note:
current configuration. For more information on the use of the system command
and its' options, see the SMS2000 Command Reference.
Altering this setting is normally not necessary, even when using VLAN
Note:
switches in conjunction with Expresso GS/MDU Chassis or MDU Lites.
port-definition {mixed | tut | vlan}
sms2000% port-definition tut
en using multiple MDU Lites behind a VLAN switch, such as a Cisco
Note: Wh
Catalyst switch where most ports can have only one non-default VLAN ID,
make sure to specify the VLAN ID of each MDU Lite when configuring its
static port. After configuration is complete, verify that it is working. First, reboot
the SMS2000, VLAN Switch, and MDU Lites. Then, "snmp-poll
000000000000". If the SMS2000 should correctly ARP for each MDU Lite on
its configured default VLAN, and immediately SNMP poll it, the command will
return promptly. If this test fails, check the VLAN configuration.
Page 34 of 104 P/N 220-06288-20
