Installation Instructions
TOOLS REQUIRED FOR INSTALLATION
3/16" (4.8mm)
5/16" (7.9mm)
PARTS
K (4)
M6 x 25
R (4)
#10
W (1)
M4 (included)
A (1)
[Wall plate]
E (4)
D (4)
M4 x 12
M7 x 70
L (4)
M8 x 25
M8 x 20
S (4)
Shoulder washer for M4 Shoulder washer for
and M5 screws
X (1)
M5
M4
M2.5 (included)
M3 (included)
M4 (included)
M5 (included)
B (2)
[Upright]
F (4)
M5 x 12
M6 x 12
M (4)
N (4)
M8 x 16
T (4)
M6 screws
Y (1)
M3
C (1)
M4
G (4)
H (4)
M4 x 25
P (4)
M8 x 10
M8 x 40
V (4)
U (4)
.5"
.25"
Z (1)
M2.5
MSTU
J (4)
M5 x 25
Q (4)
AA (4)
[Anchor]
