CHIEF Thinstall TASMS Installation Instructions Manual

Steel stud adapter

Advertisement

Quick Links

I N S T A L L A T I O N I N S T R U C T I O N S
TASMS withTS118
TAMMS with TS318
Thinstall™ Steel Stud Adapter
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
TASMS/TAMMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thinstall TASMS and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF Thinstall TASMS

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S TASMS withTS118 TAMMS with TS318 Thinstall™ Steel Stud Adapter Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description...
  • Page 2: Important Safety Instructions

    AN ACCESSORY is the secondary Chief The TASMS/TAMMS accessory is designed product which is attached to a primary Chief product, and may to be mounted to a 2" x 4"-25ga minimum steel studs wall. have a component attached or setting on it.
  • Page 3 Installation Instructions TASMS/TAMMS DIMENSIONS TASMS 6.68 169.6 THESE MOUNTING HOLES FOR TS218 THESE MOUNTING HOLES FOR TS118 6.25 8.01 5.43 13.38 158.8 203.4 4.82 138.0 339.7 122.5 THESE MOUNTING HOLES FOR TS110 2.50 63.5 TAMMS 18.00 457.2 12.34 313.4 1.50 38.1...
  • Page 4: Installation Instructions

    TASMS/TAMMS Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
  • Page 5: Tools Required For Installation

    Installation Instructions TASMS/TAMMS TOOLS REQUIRED FOR INSTALLATION 1/2" (12.7mm) 1/2" (12.7mm) PARTS Hardware bag (only 3 of each required) B (4) C (4) 1/4" 1/4-20 x 1 3/4" D (4) 1/4" anchor E (1) G (1) F (2) 1/4-20 [screw cap] 1/4"...
  • Page 6: Site Requirements

    TASMS/TAMMS Installation Instructions Site Requirements (Must be centered over stud) If back side of wall is unfinished, drywall must be installed to a minimum of one stud left and right of the studs being used to install the mount. Drywall must be secured to stud with screws 12"...
  • Page 7: Assembly And Installation

    Hold metal channel on anchor (D) flat alongside plastic straps and slide channel through hole. (See Figure 3) IMPORTANT ! : The TASMS/TAMMS accessory is designed to mount Chief’s Thinstall™ wall mounting systems to a steel studs wall. Do not attempt to install Drywall any other mounting system to this accessory.
  • Page 8 TASMS/TAMMS Installation Instructions Place adapter plate (A) over anchors and align mounting holes on mount with holes in anchors. (See Figure 6) or (TASMS) (See Figure 7) 10. Use two 1/4-20 x 1 3/4" Phillips pan machine screws (B), two screw caps (F) and two 1/4" washers (C) to secure adapter plate (A) to anchors (D) using top and bottom mounting holes.
  • Page 9 Installation Instructions TASMS/TAMMS...
  • Page 10 TASMS/TAMMS Installation Instructions...
  • Page 11 Installation Instructions TASMS/TAMMS...
  • Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...

This manual is also suitable for:

Thinstall tamms
