SM24DP4XA Quick Start Guide

Initial Switch Configuration via Web Browser

After powering up the switch for the first time, you can perform the initial
switch configuration using a web browser. For managing other switch features,
see the Web User Guide. To begin the initial configuration stage, reconfigure
your PC's IP address and subnet mask to make sure the PC can communicate
with the switch. After changing PC's IP address (for example, 192.168.1.250),
you can access the Web UI of the switch using the switch's default IP address.
Note: The switch factory default IP address is 192.168.1.77 and the default
Subnet Mask is 255.255.255.0.
1. Power up the PC that you will use for the initial configuration. Make sure the PC has the Ethernet RJ45
connector to be connected to the switch via standard Ethernet LAN cable. 2. Reconfigure the PC's IP address and
Subnet Mask so that it can communicate with the switch. 3. Power up the switch to be initially configured and
wait until it has finished its start-up processes. 4. Connect the PC to any port on the switch using a standard
Ethernet cable, and check the port LED on the switch to make sure the link status of the PC is OK. 5. Run your
Web browser on the PC; enter the factory default IP address to access the switch's Web interface. If your PC is
configured correctly, the Login page displays.
Class I, Division 2 / classe I, division 2
Warning and Caution - Proper Installation and Operation (English)
These devices are open-type devices that are to be installed in an enclosure only accessible with the use of a tool, suitable
for the environment. This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D or non-hazardous
locations only. WARNING – EXPLOSION HAZARD. DO NOT DISCONNECT WHILE THE CIRCUIT IS LIVE OR UNLESS THE AREA IS
FREE OF IGNITIBLE CONCENTRATIONS.
Avertissement et mise en garde - Installation et fonctionnement corrects (français)
Ces périphériques sont des périphériques de type ouvert qui doivent être installés dans un enceinte uniquement accessible à
l'aide d'un outil, adapté à environnement. Cet équipement peut être utilisé dans la classe I, division 2, groupes A, B, C, et D
ou des emplacements non dangereux seulement. AVERTISSEMENT - RISQUE D'EXPLOSION. NE PAS SE DÉCONNECTER
LORSQUE LE CIRCUIT EST VIVANT OU À MOINS QUE LA ZONE NE SOIT LIBRE DE CONCENTRATIONS IGNIFIABLES.
For More Information
Related manuals are: SM24DP4XA Install Guide 33769, Web User Guide 33770, and CLI Reference 33771.
For Transition Networks Drivers, Firmware, etc. go to the Product Support webpage (logon required).
For Transition Networks Manuals, Brochures, Data Sheets, etc. go to the Support Library (no logon required).
For SFP manuals see Transition Networks SFP webpage.
