PCIII connectors
i509-411
www.powercommander.com
Unplug this connector
Stock connector
PCIII harness
Ground wire
1
Remove the seat.
2
Remove the fuel tank
Note: The fuel tank does not need to be
removed to perform the install
but it will make it easier.
3
Unplug the connector from the
throttle bodies to the wiring har-
ness (Fig. A).
4
Plug the connectors from the
Power Commander in-line of the
stock connector (Fig. B).
5
Route the Power Commander
wiring harness along the left
side of the frame (Fig C).
6
Connect the ground wire from
the Power Commander to the
negative side of the battery
(Fig. C).
2003 Triumph Daytona 600 - PCIII USB - 2
