- Page 1 Radish Panic Operating Manual Warning Please read the manual before using and installing the machine.
-
Page 2: Table Of Contents
Catalog One、Machine specifications and technical parameters ............1 Two、List of machine parts....................2 Three、Fault analysis and Countermeasures ..............3-4 Four、Game description ....................5-6 4-1 Playing instrution...................... 5 4-2 Operation interface ....................5 4-3 Control signals and instructions ................6 Five、Parts Detail ......................7-17 5-1 Body Part ...................... -
Page 3: One、Machine Specifications And Technical Parameters
One、 Machine specifications and technical parameters Unit：mm Working Voltage： AC 220V±10% 50Hz Power Consumption：mix 55W ～ max 310W Shape And Size：655L×534W×1244H（mm） Weight ：≈50.8 kg Environmental Conditions：Temperature(Indoor): -10℃～+40℃； ：≤90%； Humidity Atmosphere：86Pa～106Pa。 Warning： After the shutdown, please wait 1 minutes before the boot. Notice ：... -
Page 4: Two、List Of Machine Parts
Two、List of machine parts In order to use the machine normally,Please check below parts whether or not full after opening the packing box. Assembly list below: Specification/Mat Name Unit Picture Remark erial According to Instructions shipment requirement Lottery Ticket Door、 AH57 Coin Door、... -
Page 5: Three、Fault Analysis And Countermeasures
Three、Fault analysis and Countermeasures 三、Fault analysis and Countermeasures Failure causes measures phenomenon coin selector coin selector did’t set well. Adjust the coin selector and resistance. can’t work counterfeit coin in the slot Take the counterfeit coin out Lottery machine without 12V input Check the output voltage of the power supply box and the circuit. - Page 6 Turn on power switch and insert the Without power input to the machine plug Turn on power switch the power switch didn’t turn on The power fuse burn out Check the short circuit or replace new Machine did’t fuse. Replace the power box The power box without voltage output Connect the the circuit of mainboard The mainboard without voltage...
-
Page 7: Four、Game Description
Four、Game Description 4-1 play description . Insert coin, press the start button. 2.Hitting the target on the bounce and scoring. 3.During the game time , The higher the score, the more out of the lottery. Operation interface carrot hammer control Slot Ticket outlet... -
Page 8: Control Signals And Instructions
Four-3. Control signals and instructions 1.Check the attached IO table and schematic，The plane can enter the machine motherboard, the output corresponding to the locationg of the wiring. 2.DIP adjust reference IO table，Capital letters is factory settings， the user can adjust according to the operation situation。 3. -
Page 9: Five、Parts Detail
Five、Parts Detail 5-1 Body Part Final Assembly Light Box Assembly Machine Box... - Page 10 Light Box Assembly Nmuber Figure No./GB Name Specification or material Light Box Plastic Organic film for plastic uptake suction Light box back 15mm Double white medium board fiber board Pillar Vehicle workpiece Speaker 4 inch 8Ω15W Light box’s 201 stainless steel fixed sheet metal...
-
Page 11: Coin Assembly Part
5-2 Coin Assembly Part Specification or Nmuber Figure No./GB Name material Side throw electronic Coin selector LK100M Drawer LK003C Ver2.42 Lottery box Coin box iron AH78 Lock 78 short lock Counter support Black Plastic Six bit counter C-012 CSAN.PCB Restore button... -
Page 12: Coin Selector Introduction
Black Plastic Sound adjuster 5-3 Coin Selector Instructions When the coin selector jammed,poking button as shown in the figure,coin will be backed out.If no work,it need to take apart coin selector to get the coin. The use of electronic coin comparison instructions： Ａ. -
Page 13: Speaker Assembly Part
the range will be smaller and choose the token more strictly. Ｆ. Connection description： 1. Grey wire Red wire-DC+12V 2. White wire-COIN Signal Code Table 3. Black wire - Ground wire 4. Grey wire 5-4 Speaker Assembly Part Specification or Nmuber Figure No./GB Name... -
Page 14: Electrical Installation Component Part
Ground clamp Rocker switch Electric outlet Electric wire 6.3A 5-6 Electrical Installation Component Part Specificat Nmuber Figure No./GB Name ion or material 12v 150w Power Supply Box 24v 150w Mainboard 12V Magic lantern XXH-150703A control board... - Page 15 Exhaust fan 1804U3A 001 12V Exhaust fan net Protective tube Y101124/A1 5*20 6.3A Protective tube seat HJMF-527 Filter YB10A1 Digital Tube Counter C-012...
-
Page 16: Art Designing Part
5-7 Art Designing Part Specification or Nmuber Figure No./GB Name material Light box picture Silk-screen Counter picture Surface glue Left side picture Right side picture Front door picture... - Page 17 Digital Edition picture Surface glue...
- Page 18 Specification or Nmuber Figure No./GB Name material Ticket outlet White sticker White Counter tag White Forklift tag White Repair tag High temperature and White high pressure tap White High pressure tag White Indoor tag White Group wire tag White Fuse current tag IO table...
-
Page 19: Electrical Part
5-8 Electrical Part Specificat Nmuber Figure No./GB Name ion or material Two side light bar 12V/5050RGB 软灯条/0.4M Light box light bar 12V/MX-S5050W/60CM 5050LED-12G.PCB V1.0 Mechanism light source... -
Page 20: Six、Io Table
Six、IO Table Items Setting Coin insert on off (pcs) Playing time (s) Demo sound Free play COMMON Difficulty setting DIFFICULT Items Setting Score on off record Score for 1 ticke... - Page 21 Consolation ticket (Pcs) Free Regular Mainboard：SXKJ2013.V1.0.PCB Input section： INPUT Content INPUT Content Coin signal Target Score 1 J1-1 （1） J1-9 （9） ticket dispenser feedback Target Score 2 J1-2 （2） J1-10 （10） Service/Setting button Target Score 3 J1-3 （3） J1-11 （11） Excess ticket button Target Score 4 J1-4 （4）...
- Page 22 Extended output： Content Content Content OUTPUT OUTPUT OUTPUT 1 LED light R 3 LED lightB 6 LED lightG J1-1 （1） J1-9 （9） J2-7 （17） 1 LED light G 4 LED lightR 6 LED lightB J1-2 （2） J1-10（10） J2-8 （18） 1 LED light B 4 LED lightG 7 LED lightR J1-3 （3）...
- Page 23 Press the SERVICE button again to back to the display testing (the first procedure) and execute circularly. Press the TEST button to exit the test in any procedure, output is cleared, please start the game after reset. Clear Record: Press mainboard “Test” button, then press“SERVICE”, then restart the machine can remove memory data.
