- Page 1 Space Shooting Instruction Manual Warning Before using or installing this machine, be sure to read this manual thoroughly.
-
Page 2: Table Of Contents
Space Shooting instruction Content 1、Spec and technical parameters........1 2、Parts list............2 3、Movement and placement........... 3 3-1 Movement method ..........3 3-2 How to fix the machine ........4 3-3 Do not use machine in the following places ....4 3-4 Placement ........... -
Page 3: 1、Spec And Technical Parameters
Space Shooting instruction 1、Spec and technical parameters Unit：mm 1) Working voltage： AC 220V±10% 50Hz 2) Power consumption：mix 150W ～ max455 W 3) Dimension：L1607×W807×H2076（mm） 4) Weight ：Around 204kg 5) Environmental conditions：Temp.(indoor): -10℃～+40℃； Humidity：≤90%； Atmospheric pressure：86Pa～106Pa。 Warning ： After turning off machine, please wait for 1 min and... -
Page 4: 2、Parts List
Space Shooting instruction 2、Parts list To use machine properly, please check the parts list below. Name Spec/Material Qty. Unit Picture Remark Manual shipment request Ticket door, coin AH57 door, repair door Coin box AH78 door Fuse 6.3A Power cable 1.5M... -
Page 5: 3、Movement And Placement
Space Shooting instruction 3、Movement and placement 3-1 Movement method The machine is equipped with caster below. Move the machine for short distance by adjusting the foundation, so that the caster wheel can be touched to the ground to move the machine. When the foundation touches the barrier on the ground, there is a risk of falling over. -
Page 6: How To Fix The Machine
Space Shooting instruction 3-2 How to fix the machine Please be placed on a flat and not easy to slide the ground. Please use the foundations to fix machine.（refer to the photos below） ① Loosen the nut of foundation and tighten the screw to make the castor about 5mm from the ground. -
Page 7: The Range Of Placement
Space Shooting instruction 3-5 The range of placement Machine should be placed in the following dimensions to make enough space for running the machine and ensure customer safety. Unit：mm Attention：Do not place on a sloping position, that may easily lead to accidents. -
Page 8: 4、Wiring
Space Shooting instruction 四、Wiring Connect one end of the power cable to the junction box and the other end connects to a power outlet. Please refer to the suggested voltage, or may cause any damage. To avoid unnecessary damage, be sure to check whether the socket has grounding function. - Page 9 Space Shooting instruction Attention： Do not put heavy stuff on the power cable. That could cause a short circuit, even a fire. When unplugging the power cable from the socket, please pull out by holding the plug, do not hold the wire.
-
Page 10: 5、Installation And Maintenance
Space Shooting instruction 5、Installation and maintenance Install and adjust Before installation, please check the parts list and do the assembly. The using site must be flat and firm. After the machine is placed, the adjustment seat should be adjusted horizontally to the ground. - Page 11 Space Shooting instruction Clean Machine appearance Use soft cotton cloth to clean the stains on machine. Exhaust fan Exhaust fan is one of main tools for cooling the machine, must keep the fan clean and work properly. Warning：...
-
Page 12: 6、Troubleshooting
Space Shooting instruction 6、Troubleshooting Situation Caused reason Troubleshooting Coin selector is not adjusted well. Adjust coin selector, token tolerance Can not insert There’s a fake coin stuck in coin selector Take out the fake coin the coin No input 12V Check power supplier’s voltage output and... -
Page 13: 7、Game Instruction
Space Shooting instruction 7、Game instruction 7-1 How to play 1. Insert the coin, press button to start the game. 2. Move the handle (up/down/left/right) to aim scoring target. Hit the target can score. 3. Within required time, get more scores for more tickets. -
Page 14: Control Signals And Instruction
Space Shooting instruction 7-3 Control signals and instruction Check the attached IO table, schematic diagram and the main board plan to see machine input and output corresponding to the wiring position. DIP adjustment refer to IO table. Capital letters are for the factory settings, users can adjust their own operating conditions. -
Page 15: Use And Repair
Space Shooting instruction 7-4 Use and repair 1.The machine must be powered off while it is being serviced and repaired. In order to avoid short circuit, the personnel need to turn off the machine before touching the device. If this operation requires power-on, it must comply with the operating instructions. -
Page 16: 8、Parts List
Space Shooting instruction 8、Parts list 8-1 Mechanism parts Light box assembly Monitor Assembly... - Page 17 Space Shooting instruction Light box assembly Name Spec/Material Qty. Light cover White plastic cover Light box fixer Stainless steel 201 Back plate 15mm Black Left -1 Light box holder Q235 Right -1...
- Page 18 Space Shooting instruction Monitor assembly Name Spec/Material Qty. Monitor Frame White plastic Transparent glass Monitor glass (toughened) Monitor 32 inch Monitor hooks Q235 Monitor holder Q235 Rubber cylinder...
-
Page 19: Coin Selector Assembly
Space Shooting instruction 8-2 Coin selector assembly Name Spec/Material AH57 Lock 57 Long lock Coin Selector LK100M Coin box Iron AH78 Lock 78 Short lock Ticket dispensor LK003C Ver2.42 Ticket box White plastic Counter bracket Black plastic 6 bit counter... -
Page 20: Coin Selector Instruction
Space Shooting instruction 8-3 Coin selector instruction When the coin stuck in coin selector, pull button as shown in photo, the coin will be withdrawn from it. If the coin can not be withdrawn, it is necessary to open the coin acceptor and remove the coin. -
Page 21: Speaker Assembly
Space Shooting instruction 8-4 Speaker assembly Name Spec/Material Round speaker 4 inch 8Ω15W White plastic cover Plastic Speaker light board 12V RGB Speaker net Silver 8-5 Fuse and power components Name Spec/Material Wire box Fuse base HJMF-527 Ground terminal Switch... -
Page 22: Electrical Installation Components
Space Shooting instruction 8-6 Electrical installation components... - Page 23 Space Shooting instruction Name Spec/Material Unit 12V 150W Power Supply 24V 350W 12V Light control XXH-150703A board Main board AIT20160810 Pc host MB-A31S(V1.0) Filter XXH-150703A Fuse Y101124/A1 5*20 6.3A Fuse base HJMF-527 Button White Diameter 45mm 220V 50HZ Monitor HV320WHB-N82-58PF...
-
Page 24: Artwork
Space Shooting instruction 8-7 Artwork... - Page 25 Space Shooting instruction Name Spec/Material Light box Sticker button Sticker Side of base Sticker Base Sticker Warning at the base Sticker Console Sticker Back of the seat Sticker Side plate Sticker Bilateral...
- Page 26 Space Shooting instruction Name Spec/Material White sticker Ticket gate Fork label White sticker Repair door label White sticker High temp./voltage White sticker label High voltage label White sticker Ground wire label White sticker White sticker Fuse current label Indoor use label...
-
Page 27: Electrical Parts
Space Shooting instruction 8-8 Electrical parts Name Spec/Material Monitor frame light 5050 RGB light belt 60 beads 2.8m 12V Two side light of console 5050 RGB light belt 60 beads 15cm 12V Light belt A on light box 5050B RGB light belt 60 beads 1.45m 12V...
