- Page 1 Heli Copter Instruction Warning Before using or installing this machine, be sure to read this manual thoroughly.
-
Page 2: Table Of Contents
Heli Copter instruction Content 1、Spec and technical parameters........1 2、Parts list............2 3、Movement and placement........... 3 3-1 Movement method ..........3 3-2 How to fix the machine ........4 3-3 Do not use machine in the following places ....4 3-4 Placement ........... -
Page 3: 1、Spec And Technical Parameters
Heli Copter instruction 1、Spec and technical parameters Unit：mm 1) Working voltage： AC 220V±10% 50Hz 2) Power consumption：mix110 W ～ max515 W 3) Dimension：L1730×W1358×H1910（mm） 4) Weight ：Around 205 kg 5) Environmental conditions：Temp.(indoor): -10℃～+40℃； Humidity：≤90%； Atmospheric pressure：86Pa～106Pa。 Warning： After turning off machine, please wait for 1 min and... -
Page 4: 2、Parts List
Heli Copter instruction 2、Parts list To use machine properly, please check the parts list below. Name Spec/Material Qty. Unit Picture Remark Manual shipment request Ticket door, coin 1285 door, repair door Coin box 1396 door Fuse 6.3A Power cable 1.5M... -
Page 5: 3、Movement And Placement
Heli Copter instruction 3、Movement and placement 3-1 Movement method The machine is equipped with caster below. Move the machine for short distance by adjusting the foundation, so that the caster wheel can be touched to the ground to move the machine. When the foundation touches the barrier on the ground, there is a risk of falling over. -
Page 6: How To Fix The Machine
Heli Copter instruction 3-2 How to fix the machine Please be placed on a flat and not easy to slide the ground. Please use the foundations to fix machine.（refer to the photos below） ① Loosen the nut of foundation and tighten the screw to make the castor about 5mm from the ground. -
Page 7: The Range Of Placement
Heli Copter instruction 3-5 The range of placement Machine should be placed in the following dimensions to make enough space for running the machine and ensure customer safety. Unit：mm Attention：Do not place on a sloping position, that may easily lead to accidents. -
Page 8: 4、Wiring
Heli Copter instruction 4、Wiring Connect one end of the power cable to the junction box and the other end connects to a power outlet. Please refer to the suggested voltage, or may cause any damage. To avoid unnecessary damage, be sure to check whether the socket has grounding function. - Page 9 Heli Copter instruction Attention： Do not put heavy stuff on the power cable. That could cause a short circuit, even a fire. When unplugging the power cable from the socket, please pull out by holding the plug, do not hold the wire.
-
Page 10: 5、Installation And Maintenance
Heli Copter instruction 5、Installation and maintenance Install and adjust Before installation, please check the parts list and do the assembly. The using site must be flat and firm. After the machine is placed, the adjustment seat should be adjusted horizontally to the ground. - Page 11 Heli Copter instruction Clean Machine appearance Use soft cotton cloth to clean the stains on machine. Exhaust fan Exhaust fan is one of main tools for cooling the machine, must keep the fan clean and work properly. Warning：...
-
Page 12: 6、Troubleshooting
Heli Copter instruction 6、Troubleshooting Situation Caused reason Troubleshooting Coin selector is not adjusted well. Adjust coin selector, token tolerance Can not insert There’s a fake coin stuck in coin selector Take out the fake coin the coin Volume is adjusted too low... -
Page 13: 7、Game Instruction
Heli Copter instruction 7、Game instruction 7-1 How to play 1. Insert the coin, press button to start the game. Machine swings, player complete a variety of trigger events to get score. 3. Within required time, get more scores. 7-2 Interface... -
Page 14: Control Signals And Instruction
Heli Copter instruction 7-3 Control signals and instruction 1.Check the attached IO table, schematic diagram and the main board plan to see machine input and output corresponding to the wiring position. 2.DIP adjustment refer to IO table. Capital letters are for the factory settings, users can adjust their own operating conditions. -
Page 15: Use And Repair
Heli Copter instruction 7-4 Use and repair 1.The machine must be powered off while it is being serviced and repaired. In order to avoid short circuit, the personnel need to turn off the machine before touching the device. If this operation requires power-on, it must comply with the operating instructions. -
Page 16: 8、Parts List
Heli Copter instruction 8、Parts list 8-1 Mechanism parts Light box assembly Tail propeller assembly Fiberglass Swing base mechanism... - Page 17 Heli Copter instruction Light box assembly...
- Page 18 Heli Copter instruction Name Spec/Material Qty. Top light cover Red ABS Propeller White ABS Plate D Q235 Plate E Stainless steel 201 Rib bearing F6904 Pillar Q235 Propeller shaft Big friction Aluminum alloy wheel Plate B Stainless steel 201 Plate C...
- Page 19 Heli Copter instruction Tail propeller assembly Name Spec/Material Tail propeller plastic Translucent white slice plastic Tail propeller’s white plastic cover Tail propeller’s white plastic front cover Plate of tail Q235 propeller Dual output shaft 12V10RPM motor Fixing base Q235 Cover plate of motor...
- Page 20 Heli Copter instruction Swing base mechanism Name Spec/Material Pedal A Pattern aluminum(δ1.0) bilateral Plastic base Blue ABS symmetry Base connector Stainless steel 201 Swing frame H-type optocoupler Fixed angle iron Electrolysis board Bearing with base UCFU204 Polyurethane wheels φ150X51mm Connecting flange...
-
Page 21: Coin Selector Assembly
Heli Copter instruction φ100X31mm)Total height Directional castors 130 with bearing Shaft Motor pad Q235 Each for left, Limit switch holder Stainless steel 201 right side Base 2 Neck blister Green ABS Organ cover Black cloth 8-2 Coin selector assembly Name... -
Page 22: Coin Selector Instruction
Heli Copter instruction 8-3 Coin selector instruction When the coin stuck in coin selector, pull button as shown in photo, the coin will be withdrawn from it. If the coin can not be withdrawn, it is necessary to open the coin acceptor and remove the coin. -
Page 23: Speaker Assembly
Heli Copter instruction 8-4 Speaker assembly Item No. Name Spec/Material 1.42.0001 Round speaker 4 inch 8Ω15W White plastic cover Plastic Speaker light board 12V RGB 1.22.0018 Speaker net Silver 8-5 Fuse and power components Item No. Name Spec/Material wire 1.26.0001... -
Page 24: Electrical Installation Components
Heli Copter instruction 8-6 Electrical installation components... - Page 25 Heli Copter instruction Item No. Name Spec/Material Unit Power supply 12V 150W Main board Triple filter CW2B-10A-T Middle size Transparent ∅54mm Convex SETS button Amplifier board Music amplifier.PCB V1.0 Monitor 32 inch 90-250V Solid relay SSR-10AD YL7124 0.37KW 220V 1400RPM...
-
Page 26: Artwork
Heli Copter instruction 8-7 Artwork... - Page 27 Heli Copter instruction Name Spec/Material Propeller sticker Monitor sticker Seat sticker Control panel sticker Button A sticker Button B sticker Sticker on base Spray painting...
- Page 28 Heli Copter instruction Name Spec/Material Counter label White sticker Fork label White sticker Repair door label White sticker High voltage label White sticker High temp./voltage White sticker label Repair label White sticker Indoor use label White sticker...
-
Page 29: Electrical Parts
Heli Copter instruction 8-8 Electrical parts Name Spec/Material Dome lights of top ADS-75123-2835 propeller Lights of top 12V/5050 blue light 0.75m propeller Dome lights of 12V/5050 blue light 0.15m tail propeller Frame light of 12V/5050 blue light 1.0m tail propeller...
