TRIPLE TURN Manual
1. SAFETY PRECAUTIONS
Before using this game, read the following safety precautions thoroughly and use the
game correctly.
Be sure to observe the safety instructions as they are important for ensuring safe operation
of the game.
This indicates risk that can lead to personal injury and/or property damage
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction regarding the use of the appliance by a person responsible
for their safety.
Children should be supervised while playing this game.
When opening or closing the glass door, support the glass with one hand and avoid
applying impact to the door during opening or closing. Careless handling of the glass
door can result in the pinching of your hand or the breakage of the glass causing
possible injury.
When moving the machine, exercise caution and do not push the glass section.
The glass used on the game is tempered safety glass, but it can break if excessive
force applied, thus causing possible danger to yourself and people around the
machine.
Do not allow players to tilt, lift or drop the machine, or conduct any other improper
action. Such action may cause the machine to tip over or the glass to break,thus
causing danger to people around the machine.
When installing the machine, use the leg levelers to ensure that machine does not
move easily. lf the leg levelers are not adjusted properly, the machine can move if a
light push is applied, thus causing possible danger to people around the machine.
Be careful not to pinch your fingers when adjusting the leg levelers.
The machine is very heavy. Do not place your hand under the machine.
This machine is for indoor use only. Never use the machine outdoors as rain or dust
can cause a short circuit or electric shock.
To prevent possible electric shock due to failure, this equipment MUST be fitted with
a securely connected GROUNDED plug.
Install the power cord so that people cannot step on it or in such a way that could
present a trip hazard. Route it under other machines or where it could be crushed.
Do not unplug the power cord by pulling the cord, as could break internal wires and
cause electric shock.
Do not use power cord if it becomes damaged.
If internal wires are exposed, replace the cord immediately; otherwise, a short circuit
or electric shock can occur.
.1.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIPLE TURN and is the answer not in the manual?

Questions and answers

Summary of Contents for Tecway TRIPLE TURN

  • Page 1 TRIPLE TURN Manual 1. SAFETY PRECAUTIONS Before using this game, read the following safety precautions thoroughly and use the game correctly. Be sure to observe the safety instructions as they are important for ensuring safe operation of the game. This indicates risk that can lead to personal injury and/or property damage This appliance is not intended for use by persons (including children) with reduced physical,...
  • Page 2: Specifications

    TRIPLE TURN Manual ● if you have to leave the machine unattended during maintenance or service, be sure to close and lock the glass door, coin door, and rear compartment door to prevent people from getting injured by touching the inside of the machine.
  • Page 3 TRIPLE TURN Manual 3. TEARDOWN FOR TRANSPORTATION Before turning on the power, open the top back door and remove the screw first. Remove the screw .3....
  • Page 4 TRIPLE TURN Manual 4. Installation of LCD Box Unit Top Tray L 1pcs Screw M5X20 10pcs Please open the inner cover of the machine cabinet and link the connector of the top roof to LCD Box Unit; Take off the inner cover of LCD Box Unit and connect black cable to the displayer;...
  • Page 5: Installation

    TRIPLE TURN Manual 5. INSTALLATION Install the machine according to the instructions and procedures specified in this operation manual. Failure to follow the specified procedures may result in a fire, electric shock, injury, or machine malfunction. Insert the power cord plug firmly into the power outlet. Poor contact may cause overheating that can lead to fire or burns.
  • Page 6 TRIPLE TURN Manual 6. Play Zone of Installed Machine ● Set a play zone as shown below so that players can move away from the machine without bumping into observers or passersby. ● Provide a space of at least 500mm (2 feet) between the machine and wall or other machines.
  • Page 7: Accessories List

    TRIPLE TURN Manual 7. ACCESSORIES LIST ITEM DESCRIPTION QY. PART No. ------ Key(9895) Key (9888) ------ 310-706 Pink Ball (20 pieces) 310-707 Yellow Ball (20 pieces) 310-708 Orange Ball (20 pieces) Power cord 310-553 Operation Manual 310-705 Spanner(400820202) ------ Top Tray-Left(400802801)...
  • Page 8 TRIPLE TURN Manual 9. Power switch and Ball ・Power switch There are two power switches, one is on the back and the other is inside of the service door. Both of them need to be ON to operate the game.
  • Page 9: How To Play

    TRIPLE TURN Manual 10. How to Play After a coin is inserted, the monitor on top of the game machine will display  "PUSH". When the "Launcher Unit" is flashing, you may operate "Push Handle Unit ". Notice: When it is under the setting of "Mercy Ticket", tickets will come out immediately.
  • Page 10 TRIPLE TURN Manual 11. CHANGE OF SETTINGS & CONFIRMATION OF DATA In order to ensure the machine functions properly, please check whether the voltage of the power supply box matches the value of the label directions. FUNCTION KEYS ILLUSTRATION: MAIN MENU BOOKKEEPING………………………………Confirmation of game info...
  • Page 11 TRIPLE TURN Manual BOOKKEEPING MENU GAME COUNT …Total number of games played. It will be updated when it is game over. CREDIT COUNT …Total number of credits.(SERVICE is not counted). TICKETS COUNT …Total number of ticket payout. TICKETS/GAME …Avg. number of ticket payout per game.
  • Page 12: Setting Menu

    TRIPLE TURN Manual SETTING MENU Jackpot…No. of JACKPOT ticket out(100~1000). Mercy Tickets…No. of Mercy Ticket output(0~5). Mode Switching…Change of mode(Normal Game Mode、Debug Burning Mode) Coin Set Mode… Coin insert settings(1 COIN/2CREDITS、1~10 COINS/1CREDIT) Roulette Mode…Roulette scores settings ※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※ Numbers on the roulette can be changed by adhering “number tag”stickers according to the following instructions After changing the numbers stickers on the roulette please don’t forget to change...
  • Page 13 TRIPLE TURN Manual Roulette A Roulette B Roulette C Roulette D (Number tags –A) (Number tags –C) (Number tags –D) (Default) Upper section Upper section Upper section Upper section 上 段 上 段 上 段 上 段 Middle section Middle section...
  • Page 14 TRIPLE TURN Manual Display of error log ERROR LOG : show the latest 10 Press Button ① to return to the main menu. Press Button ④ to select the item. Select YES and press Button ④ to clear records. TICKETS PAY OUT LOG MENU P Press Button ①...
  • Page 15: I/O Test Menu

    TRIPLE TURN Manual I/O TEST MENU Items displayed: in red ink…responding、rotating、lamp on (ON) in yellow ink…no responding、no rotating、lamp off (OFF) UPPER MENU: confirmation of INPUT signal MIDDLE MENU: ON/OFF of OUTPUT devices such as motor、 ticket dispenser、 air blower、 solenoid LOWER MENU: ON/OFF display of all LED Press Button②、Button ③...
  • Page 16: Error Messages

    TRIPLE TURN Manual 12. Error Messages ERR CODE ERR UNIT HOW TO RELEASE Long pipe bottom 01. TUBE BOTTOM JAM Ball gets jammed at HOPPER exit. 02. PLAY CHANNEL JAM PLAY CHANNEL; AC Power Ball is not in place; or sensor is activated when there is no ball;...
  • Page 17 TRIPLE TURN Manual 19. YELLOW BALL1 SENSOR ERROR YELLOW ROULETTE Sensor error of BALL1 for yellow roulette (respond for3seconds). 20. YELLOW BALL2 SENSOR ERROR YELLOW ROULETTE Sensor error of BALL2 for yellow roulette (respond for3seconds). 21. YELLOW HOME SENSOR YELLOW ROULETTE...
  • Page 18 TRIPLE TURN Manual 13. DISCARDING THE MACHINE ● The machine must be collected, transported and discarded in accordance with the local laws and regulations. ● When entrusting a third party to collect, transport and discard the machine, be sure to use specialist companies to perform the task.
  • Page 19: Assembly Description

    TRIPLE TURN Manual 14. Assembly description 14.1 ・・Cabinet(Unit) ITEM DESCRIPTION QY. PART No. 1 LCD Box Unit Launcher Unit Target Unit Blue Roulette Unit Yellow Roulette Unit Red Roulette Unit Blower Unit Blast Volume Regulator Unit Handel Unit Feature Boards Unit...
  • Page 20: Cabinet(Parts

    TRIPLE TURN Manual 14.2 ・・Cabinet(Parts) ITEM DESCRIPTION QY. PART No. 1 310-720 Ceiling LED LAMP(LED-PVC-750L-75P-W) 310-721 SIDE LED LAMP(LED-PVC-660L-66P-W) 310-722 SIDE LED LAMP(LED-PVC-690L-69P-W) 310-723 Floor LED LAMP(LED-PVC-750L-75P-SY) 310-724 Floor LED LAMP(LED-PVC-750L-75P-SR) 310-725 Floor LED LAMP(LED-PVC-750L-75P-SB) Fan 80x80x25T-DC12V 310-551 SPEAKER (4 inch 8Ω15W)...
  • Page 21 TRIPLE TURN Manual 14.3 ・・・LCD Box Unit 5、6、7 ITEM DESCRIPTION QY. PART No. LCD( AU 16:9 M215HW02 V0;21.5" LCD 1 310-570 PANEL ) 2 A/D Board (ALLYSTAR M03-MB) 310-571 3 KB Board(Allystar MOSB-03) 310-572 4 LED DRIVER BOARD(LDB2720MX4V70B1) 310-573 Poster LED SMD(LED-FPC-140L-84P-SR)...
  • Page 22 TRIPLE TURN Manual 14.4 ・・・Launcher Unit 3、4、5 If sensor(KR1207)ERROR: ERR CODE 02 ITEM DESCRIPTION QY. PART No. Launch SOLENOID(DC 12V 1253L) 310-750 1 2 Sensor (KR 1207) 310-577 Launch LED SMD(LED-FPC-80L-48P-SR) 310-751 Launch LED SMD (LED-FPC-80L-48-SY) 310-752 Launch LED SMD (LED-FPC-80L-48P-SB)
  • Page 23 TRIPLE TURN Manual 14.5 ・・・Target Unit If sensor(KR1207)ERROR: ERR CODE: 32 You cannot end the current game and start the next game. ITEM DESCRIPTION QY. PART No. Sensor (KR 1207) 310-577 Leading LED SMD(LED-FPC-90L-54P-SR) 310-765 Roulette Leading RED(400804210A) 310-766 Roulette Leading YELLOW(400804211A)...
  • Page 24 TRIPLE TURN Manual 14.6 ・・・Blue Roulette Unit In order to ensure normal operation, after the machine being in operations, check if the screws of elements "7", "8", "9", "10" are loosen. If the screws are loosen, please fasten them before you start operating the machines.
  • Page 25 TRIPLE TURN Manual 14.7 ・・・Yellow Roulette Unit In order to ensure normal operation, after the machine being in operations, check if the screws of elements "7", "8", "9", "10" are loosen. If the screws are loosen, please fasten them before you start operating the machines.
  • Page 26 TRIPLE TURN Manual 14.8 ・・・Red Roulette Unit In order to ensure normal operation, after the machine being in operations, check if the screws of elements "7", "8", "9", "10" are loosen. If the screws are loosen, please fasten them before you start operating the machines.
  • Page 27: Blower Unit

    TRIPLE TURN Manual 14.9 ・・・Blower Unit ITEM DESCRIPTION QY. PART No. 1 BLOWER(DG-100-11) 310-562 2 SSR(KD20C15AX) 310-563 14.10 ・・・Handle Unit ITEM DESCRIPTION QY. PART No. 1 310-601 Bearing Bolts(M6X22DX7H-YOK-DR22) 2 Sensor (HQ SSR-DOWN) 310-755 .27....
  • Page 28 TRIPLE TURN Manual 14.11 ・・・Feature Boards Unit PCB Unit Driver Parts List: Sign Parts Launch SOLENOID (0.75A) LED CUP LAMP (0.75A) Ceiling LED LAMP (0.75A) Launch DC Motor (1.5A) Launch LED SMD (0.75A) Floor LED SMD (0.75A) Poster LED SMD (0.75A) Revolve DC motor-B (1.5A)
  • Page 29 TRIPLE TURN Manual 14.12 ・・・Coin /Redemption Door Unit For Asia ITEM DESCRIPTION QY. PART No. 310-665 1 Coin Selector( TW-800-PLUS ) Counter (OA-126) 310-648 Key Board Unit (CRKB-001) 310-649 Power Switch(SS-005AC) 310-650 Redemption (TL-001B) 310-786 310-651 Door Lock(9895 17L) Case Lock(9888 17L)
  • Page 30 TRIPLE TURN Manual 14.13 ・・・Power Supply Unit PART No. ITEM DESCRIPTION QY. PC Power Supply (MW-PD-110) 310-790 1 Power Supply (SP-100-12 ) 310-791 Power Supply (SP-200-12 ) 310-792 14.14 ・・・PC Box Unit ITEM DESCRIPTION QY. PART No. Pc Board(JMGB-M03: VIA NANO 1...
  • Page 31: Hopper Unit

    TRIPLE TURN Manual 14.15 ・・・Hopper Unit ITEM DESCRIPTION QY. PART No. 1 Hopper Disk Unit 310-800 2 Sensor (HQ SSR-UP ) 310-756 3 DC motor(DC24V 15R.P.M.) 310-801 4 Motor Driver Board (JMGB-G083-005; 1.5A) 310-641 14.16 ・・・Send Ball Unit ITEM DESCRIPTION QY....
  • Page 32: Wire Harness Diagram

    TRIPLE TURN Manual 14.17 ・・・AC Power Input Unit ITEM DESCRIPTION QY. PART No. 1 Power switch(SS-005AC 250V/4A 50/60HZ;) 310-554 2 AC OUTLET (AC 250V/15A R-301(B00) ) 310-556 14.18 ・・・Blast Volume Regulator Unit If the ball coming out of the tube located on top...
