- Page 1 Warning Before using the machine, please read carefully this Instruction.
-
Page 2: Table Of Contents
Kid Racing Instruction Content Content ......................1 一、Machine specifications and technical parameters........2 二、Spare parts with machine list ..............3 三、Instructions of moving,transportation and placement........ 4 3-1 Moving method ..................4 3-2 Fixed machine method ................ 5 3-3 DO not use the machine in this place ..........5 3-4 Placement place .................. -
Page 3: 一、Machine Specifications And Technical Parameters
Kid Racing Instruction 一、Machine specifications and technical parameters Unit：mm 1) Working voltage： 220V or 110V (note：Actual voltage please check the machine plate) 2) consumed power：mix 150～max 300W 3) Out look size：L1217×W1351×H2205（mm） 4) Weight ：almost 140.9 kg 5) Environmental conditions：Temperature(indoor): -10℃～+40℃；... - Page 4 Kid Racing Instruction 二、Spare parts list with machine For you to use this machine, please open the packing box, carefully check the following items are complete. Parts list is as follows： specifications/ Quanti Name Unit picture remarks material As customer 本...
-
Page 5: 三、Instructions Of Moving,Transportation And Placement
Kid Racing Instruction 三、Instructions of moving, ransportation and placement 3-1 Moving method Below the machine equipped with casters, short distance moving machine, adjust the anchor seat increased for casters contact ground to promote the machine can be. Foot against a ground fault code objects have overturned the... -
Page 6: Fixed Machine Method
Kid Racing Instruction 3-2 Fixed machine method please put in the flat and not easy to slide on the ground; Please use the following anchor machine - fixed the machine (as shown below) ① The lock nut with the wrench loosen anchor, anchor bolt, let casters from the ground about 5mm. - Page 7 Kid Racing Instruction behavior cause machine damage.
-
Page 8: Placement Range And Size
Kid Racing Instruction 3-5 Placement range and size The machine should be placed in the following dimensions; there is enough space for the operation of the machine, and to ensure customer safety. Note: the machine can not be placed in an inclined position, placed in an inclined position prone to accidents. -
Page 9: 四、Wiring And The Attention Item
Kid Racing Instruction 四、Wiring and the attention item The end of the wire box machine access wiring to power line, the power line plugs the other end socket. Please access the power according to the voltage - machine identification. - Page 10 Kid Racing Instruction Warning： The power line is not heavy down, this will damage the wires easily lead to short-circuit, may lead to serious fires. While the power line from the socket, should grasp and pull the plug, not catch wire pulled out.
-
Page 11: 五、Set Up And Maintain
Kid Racing Instruction 五、set up and maintain Installation and commissioning Before the installation is, please click the list of approved parts, components assembly; The use of the site must be smooth and solid, when in place to adjust the machine to the ground level of the fixed seat;... - Page 12 Kid Racing Instruction and not let anything that make it acidic and stick to the touch screen. The exhaust fan Exhaust fan is the main tool of internal cooling machine is one of the must exhaust fan clean normal operation, to maintain the smooth flow of air outlet.
-
Page 13: 六、Fault Analysis And Solution
Kid Racing Instruction 六、Fault analysis and solution Failure Possible failure reasons Fault countermeasure phenomenon The coin is not adjusted. The adjustment of the coin, token No way to pay The slot card is counterfeit. tolerance trimmer. coin Remove the counterfeit card. -
Page 14: 七、Game Instruction
Kid Racing Instruction Adjust the RGB color in the OSD menu Display settings are incorrect. or choose color. The display Select the AUTOSET key to adjust the has a color color of the display. difference The visual angle of the display is a Adjust display position. -
Page 15: Control Signal And Instruction
Kid Racing Instruction screen screen coin coin Steering Steering wheel wheel Start button Start button 7-3 Control signals and instructions 1 check the attached table and IO diagram, the motherboard can input plane machine, the output corresponding to the connection position. - Page 16 Kid Racing Instruction 3 motherboard schematic diagram: Reset button test service The above instructions are subject to change without notice, please forgive me！...
-
Page 17: Use And Maintenance Instructions
Kid Racing Instruction 7-4 Use and maintenance instructions 1 to maintain and repair the machine must turn off the power supply. In order to avoid short circuit, the relevant personnel in the internal device in contact with the device before the power off, If this operation requires the power to be connected, the operating instructions are required. -
Page 18: 八、Detail Of Spare Parts
Kid Racing Instruction 八、Detail of spare parts 8-1 Instruction part Total setting... - Page 19 Kid Racing Instruction Steering wheel spare parts:...
-
Page 20: Inset Coin Spare Parts
Kid Racing Instruction 8-2 Inset coin spare parts Name Specifications and materials quantity Side cast electronic type Coin accept LK100M Coin door Iron Coin box Iron AH78 lock 78 short lock AH57 lock 57 long lock Ticket dispenser LK003C Ver2.42... -
Page 21: Ticket Dispenser Instruction
Kid Racing Instruction Ticket Dispenser Instruction The use of lottery machine instructions: the lottery will be inserted into the slot, the opportunity to automatically start the device. (hold down the forward button can also be manually loaded) connected power and signal line to use. -
Page 22: Speaker Parts
Kid Racing Instruction Speaker parts Name Specifications and materials Quantity Circular Triton speaker 4inch 8欧15W 8-5 Insurance tube and power module name Specifications and materials Quantity Base of insurance tube Power cord 6.3A... -
Page 23: Electrical Installation Component
Kid Racing Instruction Rocker switch Wire box Terminal 8-6 Electrical installation component Name Specifications and materials Quantity Unit 5V 150W 个 Power Supply 12V 150W 块 mainboard SXKJ-2013.PCB VER1.0 块 Board control light 个 1804U3A 001 12V 个 Fun net 个... -
Page 24: Art Section
Kid Racing Instruction 8-7 Art section Name Specifications and materials Quantity Light box picture（up） Light box picture（down） Left same as 过 UV Picture by two side White adhesive right Left same as Picture by the side of the Screen right 过... - Page 25 Kid Racing Instruction 座椅背画面 过 UV White adhesive...
- Page 26 Kid Racing Instruction Name Specifications and materials Quantity Inset coin sticker White adhesive Ticket sending sticker White adhesive Chinese counter sticker White adhesive Ticket dispenser repair sticker White adhesive Contact floor sticker White adhesive Power supply use indoor label White adhesive...
-
Page 27: Electronic Parts
Kid Racing Instruction 8-8 Electronic parts... - Page 28 Kid Racing Instruction Name Specifications and materials Quantity Unit Light bar of light box by two 条 12V RGB aluminum light 5CM side 0805 12V green length 0.8m 条 Light box back light bar width 6mm 条 LED light bar MX-S5050W 700mm 条...
-
Page 29: 九、Io Table
Kid Racing Instruction 九、IO table Mainboard：LFKJ-2014.PCB Imput part： content content INPUT INPUT 1P inset coin 2P inset coin J9-1 （1） J9-9 （9） 2P ticket dispenser 1P ticket dispenser feedback J9-2 （2） J9-10 （10） feedback 1P start button 2P start button J9-3 （3）... - Page 30 Kid Racing Instruction 中山市港口镇众宇游艺设备厂 中国广东省中山市港口镇穗安工业区迎富二路三号 邮编：528400...
