Connecting the PoE+ Power Injector

Extron recommends the Extron PI 140 power injector (see figure 3). Your power
injector may look different.
Use an Ethernet cable to connect the LAN/PoE+ port of the TLI Pro 201 to the
1.
power output of the 803.3at, class 4 compliant PoE+ power injector.
Connect the network input of the power injector to a network switch or router.
2.

Front Panel Features

R MENU
A A A B B B C C C
Figure 4. TLI Pro 201 Front Panel
A Power LED — Indicates the power status and the reset status of the unit.
B Reset button (recessed) — allows the unit to be reset in any of three different modes. It also allows the user to toggle
between enabling and disabling the DHCP client. A brief summary of the reset modes is given on the next page. For more
information see the TLI Pro 201 User Guide.
C Menu button (recessed) — opens the
Setup Menu
Press the button briefly (less than 3 seconds) to open the internal menu screens.
1.
Press the button briefly for a second time to exit the setup menu.
2.
Calibration Screen
Press and hold the button (3 seconds or more) to open the
1.
calibrate the touchpanel.
Complete the calibration process or press the button briefly (less than 2 seconds) for a second time to exit the
2.
Calibration
D
Status LEDs —
Signal
The LEDs light green when a video signal is detected and are unlit when no signal is detected.
•
HDCP
The LEDs light green when HDCP content is detected and are unlit when HDCP content is not detected.
•
INPUT OUTPUT
SIGNAL
HDCP
D D D
Setup Menu
screen.
TLI Pro 201
Calibration
(see the next page) and
Calibration
screen. Follow the on-screen instructions to
Product Category
100-240V 50/60 Hz
1.1A MAX
INPUT OUTPUT
LAN POWERED TLP
To network switch To interface
Figure 3. PI 140 Power Injector
screen for the TLI Pro 201:
3
