Choose the connection mode, the setting is same as Port U1. Then connection of both the Port D and
Port U of One Sending Card to LED Display is finished.
Rendering is as follows:
3. Connect the Port D and Port U of Two Sending Cards to LED Display
(1) First, make sure the device is in normal operation. The red power indicator lights when
device has power supply and the green signal indicator lights when device has signal
input.
(2) Choose the input signal, for example, choose DVI.
(3) Connect four cables to Port U1, Port D1, Port U2 and Port D2 respectively.
(4) Connect Port D1 and Port U1 of No.1 Sending Card to LED display, the settings are
same as "Connect the Port D and Port U of One Sending Card to LED Display".
(5) Same as above, connect Port D2 and Port U2 of No.2 Sending Card to LED display.
(6) Turn the knob, choose <DISPLAY CONNECTION>, push the knob to confirm, turn the
knob again, choose <SENDING CARD NO.>, push the knob to confirm, turn the knob,
choose NO.2, push the knob to confirm.
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
>
CONNECTION MODE
SEND TO RECEIVER
17
Tel: 00865925771197
Email: sales@rgblink.com
Fax: 00865925771202
http://www.rgblink.cn
