RGBlink VSP 9516S Quick Start Manual page 14

(7) Choose <PORT U>, and set the horizontal card, vertical card, width and height.
For example, set horizontal card as 2, vertical card as 3, width and height as 120,
shown as follows:
The setting is as follows:
(8) After setting, turn the knob, choose <DISPLAY CONNECTION>, push the knob to
confirm, turn the knob again, and choose <CONNECTION MODE>. VSP 9516S
supports 8 kinds of connection modes, they are
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
>
CHOOSE CABLE
HORIZONTAL CARD
VERTICAL CARD
WIDTH
>
CHOOSE CABLE
HORIZONTAL CARD
VERTICAL CARD
WIDTH
>
HEIGHT
D PORT Offset (A/B) X
D PORT Offset (A/B) Y
DISPLAY CONNECTION
PORT D
1
1
64
PORT U
2
3
120
120
0
0
>>
, , ,
13
