RGBlink VSP 9516S Quick Start Manual page 16

(4) Connect Port U1 of No.1 Sending Card to LED display, the settings are the same as
Step 4 to Step 8 of "Connect the Port D or Port U of One Sending Card to LED
Display".
(5) Connect Port D1 of No.1 Sending Card to LED display, setting steps are as follows:
a. Turn the knob, choose <SENDING CARD TYPE>, push the knob to confirm, turn the
knob, choose the sending card type, for example, choose Linsn (VSP 9516S can only
support Linsn and Colorlight sending card). Shown as follows:
b. Turn the knob, choose <SENDING CARD NO.>, push the knob to confirm, turn the
knob, choose NO.1, push the knob to confirm.
c. Turn the knob, choose <QUICK CONNECTION>, push the knob to confirm. Turn the
knob, choose <RECEIVING CARD SET>, push the knob to confirm, and enter to the
to the next level menu, the OLED module show as follows:
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
>
SENDING CARD TYPE
SENDING CARD NO.
BRIGHTNESS
QUICK CONNECTION
*
SENDING CARD TYPE
SENDING CARD NO.
BRIGHTNESS
QUICK CONNECTION
SENDING CARD TYPE
>
SENDING CARD NO.
BRIGHTNESS
QUICK CONNECTION
SENDING CARD TYPE
SENDING CARD NO.
BRIGHTNESS
>
QUICK CONNECTION
COLOR LIGHT
NO.1
50%
>>
LINSN
NO.1
50%
>>
LINSN
NO.1
50%
>>
LINSN
NO.1
50%
>>
15
