Product Introduction

VSP 9516S is the first LED video processor
developed by RGBlink which does support the
LED display connection function. It supports
inputs including 3×CVBS, 1×S-Video, 1×YPbPr,
1×VGA, 1×DVI-I (compatible with HDMI),
1×Displayport, 1×3G-SDI, up to 9 channels
inputs, and 2×DVI-I, 1×VGA, up to 3
simultaneous outputs. VSP 9516S is not only a
video scaler for video and graphic processing or
just provides power and makes room for the
sending cards to install inside.
System Connection
RGBlink offers solutions to
demanding technical problems.
Any application questions, or
required further information,
please contact with our
customer Support Engineers.
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
VSP 9516S embedded a special menu for
local control LED display by its each LED
sending card in connected, operator will easily
operate display
adjustment, Gamma correction by <DISPLAY
CONNECTION>
sending card model.
VSP 9516S integrates Display Setting Remote
Control Interface with the video processing
remote control software also, operator will
have more remote control options.
VSP 9516S System Connection Diagram
2
Tel: 00865925771197
Email: sales@rgblink.com
connection, brightness
menu after decide
Fax: 00865925771202
http://www.rgblink.cn
the
