d. Turn the knob, choose <CHOOSE CABLE>, push the knob to confirm. Turn the knob,
choose <PORT D>, push the knob to confirm.
e. Turn the knob, and choose <D PORT Offset (A/B) Y>, and set D PORT Offset (A/B) Y
as 240 (Note: D PORT Offset (A/B) Y=HORIZONTAL CARD×HEIGHT, before we set
horizontal card as 2 and height as 120). Shown as follows:
f. Turn the knob, choose <DISPLAY CONNECTION>, push the knob to confirm, turn the
knob again, and choose <CONNECTION MODE>. the OLED module show as follows:
Address:S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
SENDING CARD SET
>
RECEIVING CARD SET
>
CHOOSE CABLE
HORIZONTAL CARD
VERTICAL CARD
WIDTH
>
CHOOSE CABLE
HORIZONTAL CARD
VERTICAL CARD
WIDTH
>
HEIGHT
D PORT Offset (A/B) X
D PORT Offset (A/B) Y
DISPLAY CONNECTION
HEIGHT
D PORT Offset (A/B) X
D PORT Offset (A/B) Y
>
DISPLAY CONNECTION
>>
>>
PORT U
2
3
120
PORT D
2
3
120
120
0
240
>>
120
0
240
>>
16
