Bill of Materials, PCB Layout, and Schematics
7.3
Schematics
The schematics for the ADSxx53EVM are appended to the end of this user's guide.
32
ADS8353EVM-PDK and ADS7853EVM-PDK
Figure 34. ADSxx53EVM PCB: Power Layer
Figure 35. ADSxx53EVM PCB: Bottom Layer
Copyright © 2014, Texas Instruments Incorporated
SBAU210A – June 2014 – Revised August 2014
Submit Documentation Feedback
www.ti.com
