eBOX640-521-FL Series User's Manual
3.3.1
DC Jack Power Connector (CN1)
The CN1 is a DC jack with screw supporting the 12V, 19-
24VDC power input connector. Firmly insert an adapter
with at least 90W power supply into this connector. Loose
connection may cause system instability and make sure all
components/devices
connecting.
Screw metric thread size: M8.0x0.75.
【Note】
3.3.2
USB 2.0 Stack Port (CN2)
The motherboard comes with one stacked Universal Serial Bus (compliant with USB
2.0) connector on the rear I/O for installing USB peripherals such as a keyboard,
mouse, scanner, etc.
Pins
Signals
1
USB_PWR
3
USB#5_D-
5
USB#5_D+
7
GND
3.3.3
USB 3.0 Stack Port (CN3)
The motherboard comes with one stacked Universal Serial Bus (compliant with USB 3.0)
connector on the rear I/O for installing USB peripherals such as a keyboard, mouse, scanner,
etc.
Pins
Signals
1
USB_PWR
2
USB#1_D-
3
USB#1_D+
4
GND
5
SSRX1-
6
SSRX1+
7
GND
8
SSTX1-
9
SSTX1+
22
are
properly
installed
Pins
Signals
2
USB_PWR
4
USB#6_D-
6
USB#6_D+
8
GND
Pins
Signals
10
USB_PWR
11
USB#2_D-
12
USB#2_D+
13
GND
14
SSRX2-
15
SSRX2+
16
GND
17
SSTX2-
18
SSTX2+
before
Jumper & Connector Settings
