Transition Networks SSETF10XX-200 User Manual page 5

5. Is the RXC LED flashing?
NO
• If there is no activity on the 10Base-T/100Base-TX port, proceed to
step 6.
• If there is activity on the 10Base-T/100Base-TX port, disconnect and
reconnect the 10Base-T/100Base-TX cable to restart the initialization
process.
• Restart the workstation to restart the initialization process.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 6.
6. Is the RXF LED flashing?
NO
• If there is no activity on the 10Base-FL/100Base-SX port, continue
below
• If there is activity on the 10Base-FL/100Base-SX port, disconnect and
reconnect the 10Base-FL/100Base-SX cable to restart the initialization
process.
• Verify that TX and RX cables on Media Converter are connected to
RX and TX ports, respectively, on other device.
• Restart the workstation to restart the initialization process.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
techsupport@transition.com -- Select the "Transition Now" Link for a Live Web Chat
SSETF10xx-200
CONTACT US
Technical Support
Technical support is avialable 7:00 AM - 6:00 PM CST (GMT -6:00)
US and Canada:
International:
Transition NOW
Chat live via the Web with TRANSITION Networks Technical Support.
Log onto www.transition.com and click the TRANSITION NOW link.
Web-Based Seminars
TRANSITION Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
techsupport@transition.com
Address
TRANSITION Networks
6475 City West Parkway
Minneapolis, MN 55344, USA
telephone:
toll free:
fax:
Name of Mfg:
Model:
Part Number(s):
Regulation:
Purpose: To declare that the SSETF10xx-200 to which this declaration refers is in
conformity with the following standards.
EN55022:1994; EN 55024:1998; FCCPart 15 Class A & B; EN 60950 A4: 1997; UL 1950
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
Stephen Anderson, Vice-President of Engineering
9 10
Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST (GMT-6:00)
1-800-260-1312
00-1-952-941-7600
952-941-7600
800-526-9267
952-941-2322
DECLARATION OF CONFORMITY
Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
SSETF10xx-200 Series Media Converters
SSETF1011-200, SSETF1013-200
EMC Directive 89/336/EEC
_April 16, 2002_____
Date
