Transition Networks SSDTF3011-110 User Manual

COMPLIANCE INFORMATION

UL Listed
C-UL Listed (Canada)
CISPR22/EN55022 Class A + EN55024
CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will be required to
correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus
set out on the radio interference regulations of the Canadian Department of
Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la class A prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb
dieses Gerätes Rundfunkstörungen auftreten, in weichen Fällen der Benutzer für
entsprechende Gegenmaßnahmen werantwortlich ist.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de
créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les
measures spécifiques appropriées
Trademark Notice
All registered trademarks and trademarks are the property of their respective owners.
Copyright Restrictions
© 2001, 2002 TRANSITION Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any
means – graphic, electronic, or mechanical – without written permission from TRANSITION
Networks.
Printed in the U.S.A.
8
TRANSITION Networks SSDTF30xx-110 series media converters encode
and decode E1 coax copper signals over duplex fiber-optic cable to extend
the distance and transmission reliability of high speed E1 data traffic.
SSDTF3011-110
Provides a set of coax copper input and
output connectors for E1 signals and a
set of RX/TX ST connectors to 850 nm
multimode duplex fiber-optic cable.
SSDTF3012-110
Provides a set of coax copper input and
output connectors for E1 signals and a
set of RX/TX ST connectors to 1300 nm
singlemode duplex fiber-optic cable.
SSDTF3013-110
Provides a set of coax copper input and
output connectors for E1 signals and an
RX/TX SC connector to 850 nm
multimode duplex fiber-optic cable.
SSDTF3014-110
Provides a set of coax copper input and
output connectors for E1 signals and an
RX/TX SC-SM connector to 1300 nm
singlemode duplex fiber-optic cable.
*In SSDTF30xx model designation, 30
represents the E1 coax input and output
connectors; xx represents the selectable fiber
connector installed on the media converter.
33218.B
E1 Coax Copper
Media Converters
SSDTF30xx*-110
USER'S GUIDE
SSDTF3015-110
Provides a set of coax copper input and
output connectors for E1 signals and an
RX/TX SC-LH connector to 1300 nm
singlemode duplex fiber-optic cable.
SSDTF3022-110
Provides a set of coax copper input and
output connectors for E1 signals and a
set of RX/TX ST connectors to 1300 nm
singlemode duplex fiber-optic cable.
SSDTF30xx in the Network . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . .4
Fault Isolation and Correction . . . . .5
Cable Specifications . . . . . . . . . . . . .6
Technical Specifications . . . . . . . . . .7
Compliance Information . . . . . . . . . .8
Fiber
to
(long haul)
(long haul)
