User's Guide
SSDTF30xx-11x
Stand-Alone Device
•
•
Transition Networks SSDTF30xx-11x series
Devices encode and decode E1 coax copper signals
over fiber optic cable to extend the distance and
transmission reliability of high-speed E1 data traffic.
The SSDTF30xx-1xx is framing independent (as ESF vs. D4) and supports all common
line codes (e.g., AMI, B8ZS, HDB3).
The SSDTF30xx-11x is designed to be installed in pairs. For example, install one
SSDTF3011-115 as the local Device and another SSDTF3011-115 as the remote Device.
Part Number
Port One - Copper
SSDTF3011-115
75 ohm BNC coax
100 m (328 ft.)*
SSDTF3012-115
75 ohm coax
100 m (328 ft.)*
SSDTF3013-115
75 ohm coax
100 m (328 ft.)*
SSDTF3014-115
75 ohm coax
100 m (328 ft.)*
SSDTF3015-115
75 ohm coax
100 m (328 ft.)*
SSDTF3016-115
75 ohm coax
100 m (328 ft.)*
SSDTF3017-115
75 ohm coax
100 m (328 ft.)*
SSDTF3018-115
75 ohm coax
100 m (328 ft.)*
SSDTF3022-115
75 ohm coax
100 m (328 ft.)*
SSDTF3025-115
75 ohm coax
100 m (328 ft.)*
SSDTF3027-115
75 ohm coax
100 m (328 ft.)*
* Typical maximum cable distance. Actual
distance is dependent upon the physical
characteristics of the network.
E1 with Remote Management
Coax (BNC) to Fiber
Port Two - Duplex Fiber-Optic
ST, 850 nm multimode
2 km (1.2 miles)*
ST, 1310 nm single mode
8 km (4.8 miles)*
SC, 850 nm multimode
2 km (1.2 miles)*
SC, 1310 nm single mode
20 km (12.4 miles)*
SC, 1310 nm single mode
40 km (24.8 miles)*
SC, 1310 nm single mode
60 km (37.3 miles)*
SC, 1550 nm single mode
80 km (49.7 miles)*
MT-RJ, 1300 nm multimode
2 km (1.2 miles)*
ST, 1310 nm single mode
15 km (9.3 miles)*
MT-RJ, 1310 nm single mode
20 km (12.4 miles)*
ST, 1300 nm multimode
5 km (3.1 miles)*
Installation . . . . . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . . . . . .6
Cable Specifications . . . . . . . . . . . . . .6
Technical Specifications . . . . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . . . . .9
Compliance Information . . . . . . . . .12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Transition Networks SSDTF3011-115
Summary of Contents for Transition Networks SSDTF3011-115
- Page 1 The SSDTF30xx-1xx is framing independent (as ESF vs. D4) and supports all common line codes (e.g., AMI, B8ZS, HDB3). The SSDTF30xx-11x is designed to be installed in pairs. For example, install one SSDTF3011-115 as the local Device and another SSDTF3011-115 as the remote Device. Part Number Port One - Copper...
-
Page 2: Remote Management
CSDTF30xx-11x, the chassis version of the Device. For example, a local CSDTF3011-115 device (that is installed in a managed Transition Networks PointSystem™ chassis) is connected, via fiber, to a remote SSDTF3011-115 device. An example of a managed single-fiber network has a local CSDTF3029-115 device connected, via fiber, to a remote SSDTF3029-116. -
Page 3: Troubleshooting
SSDTF30xx-11x Installation -- Continued Set the Configuration Switches The configuration switches are located on the side of the Device. Not Used Key: DOWN Use a small, flat-blade screwdriver or a similar device to set the recessed switches. Transmit All Ones (switches 1 & 2) The Transmit All Ones function allows the insertion of an “all ones”... -
Page 4: Power The Device
Fiber Cable Single mode fiber (recommended): 9 µm Multimode fiber (recommended): 62.5/125 µm Multimode fiber (optional): 100/140, 85/140, 50/125 µm SSDTF3011-115 850 nm multimode Fiber Optic Transmitter Power: min: -14.0 dBm Fiber Optic Receiver Sensitivity: min: -25.0 dBm Link Budget: 11.0 dB... - Page 5 SSDTF30xx-11x Installation -- Continued Set the Configuration Switches The configuration switches are located on the side of the Device. Not Used Key: DOWN Use a small, flat-blade screwdriver or a similar device to set the recessed switches. Transmit All Ones (switches 1 & 2) The Transmit All Ones function allows the insertion of an “all ones”...
- Page 6 Declaration of Conformity Name of Mfg: Transition Networks 10900 Red Cricle Drive Minnetonka MN 55343 U.S.A. Model: SSDTF30xx-11x Series Device Part Number: SSDTF3011-115, SSDTF3012-115, SSDTF3013-115, SSDTF3014-115, SSDTF3015-115, SSDTF3016-115, SSDTF3017-115, SSDTF3018-115, SSDTF3022-115, SSDTF3025-115, SSDTF3027-115, SSDTF3029-115, SSDTF3029-116, SSDTF3029-117, SSDTF3029-118 Regulation: EMC Directive 89/336/EEC Purpose: To declare that the SSDTF30xx-11x to which this declaration refers is in conformity with the following standards.
-
Page 7: Compliance Information
Compliance Information CISPR22/EN55022 Class A + EN55024 CE Mark FCC Regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
