Product Features -- Continued
Full Duplex Network
In a full-duplex network, maximum cable lengths are determined by the type
of cables that are used. See page 1 (front cover) for the cable specifications
for the different E-100BTX-FX-05(10x) models.
The 512-Bit Rule does not apply in a full-duplex network.
Half-Duplex Network (512-Bit Rule)
In a half-duplex network, the maximum cable lengths are determined by the
round trip delay limitations of each Fast Ethernet collision domain. (A
collision domain is the longest path between any two terminal devices, e.g. a
terminal, switch, or router.)
The 512-Bit Rule determines the maximum length of cable permitted by
calculating the round-trip delay in bit-times (BT) of a particular collision
domain. If the result is less than or equal to 512 BT, the path is good.
For more information on the 512-Bit Rule, see the white paper titled "Collision
Domains" on the Transition Networks website at:
http://www.transition.com/learning/whitepapers/colldom_wp.htm
6 Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST (GMT-6:00)

Cable Specifications

The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate:
Singlemode fiber (recommended):
Multimode fiber (recommended):
Multimode fiber (optional):
E-100BTX-FX-05(100)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
E-100BTX-FX-05(101)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
E-100BTX-FX-05(102)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
E-100BTX-FX-05(103)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
techsupport@transition.com -- Select the "Transition Now" Link for a Live Web Chat
<10-9
9 µm
62.5/125 µm
100/140, 85/140, 50/125 µm
1310 nm (TX) / 1550 nm (RX) simplex
min: -13.0 dBm max: -6.0 dBm
min: -32.0 dBm max: -3.0 dBm
19.0 dB
1550 nm (TX) / 1310 nm (RX) simplex
min: -13.0 dBm max: -6.0 dBm
min: -32.0 dBm max: -3.0 dBm
19.0 dB
1310 nm (TX) / 1550 nm (RX) simplex
min: -8.0 dBm max: -3.0 dBm
min: -33.0 dBm max: -3.0 dBm
25.0 dB
1550 nm (TX) / 1310 nm (RX) simplex
min: -8.0 dBm max: -3.0 dBm
min: -33.0 dBm max: -3.0 dBm
25.0 dB
7
