-NLP-01
-N-01
powered. These converters are designed to install directly inside a PC workstation
or file server and mount on any slot on a standard PCI. No additional power
supply is needed since the power is drawn directly from the PCI slot. Two LEDs
allow for network monitoring.
The E-100BTX-FX-N-01 series media converter is 4.8 in. (121 mm) wide while the
E-100BTX-FX-NLP-01 series media converter is 3.2 in (80 mm) wide.
Part Number
Port One - Copper
100Base-TX
E-100BTX-FX-N-01
RJ-45
E-100BTX-FX-NLP-01
100 m (328 ft)*
E-100BTX-FX-N-01(SC)
RJ-45
E-100BTX-FX-NLP-01(SC)
100 m (328 ft)*
E-100BTX-FX-N-01(SM)
RJ-45
E-100BTX-FX-NLP-01(SM)
100 m (328 ft)*
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network installation.
USER'S GUIDE
E-100BTX-FX-N-01
E-100BTX-FX-NLP-01
PCI Media Converter
• Ethernet
• Copper to Fiber
• 100Base-TX to 100Base-FX
Transition Networks E-100BTX-FX-N-01
and E-100BTX-FX-NLP-01 series media
converters
connect
100Base-TX
twisted-pair copper cables to 100Base-
FX fiber optic cables and are PCI
(Peripheral Component Interconnect)
Port Two - Duplex Fiber-Optic
100Base-FX
ST, 1300 nm multimode
2 km (1.2 miles)*
SC, 1300 nm multimode
2 km (1.2 miles)*
SC, 1310 nm single mode
20 km (12.4 miles)*
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .4
Cable Specifications . . . . . . . . . . .5
Technical Specifications . . . . . . . .6
Troubleshooting . . . . . . . . . . . . . .7
Compliance Information . . . . . . . .8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Transition Networks E-100BTX-FX-N-01
Summary of Contents for Transition Networks E-100BTX-FX-N-01
- Page 1 USER’S GUIDE E-100BTX-FX-N-01 E-100BTX-FX-NLP-01 PCI Media Converter • Ethernet • Copper to Fiber -NLP-01 • 100Base-TX to 100Base-FX Transition Networks E-100BTX-FX-N-01 and E-100BTX-FX-NLP-01 series media -N-01 converters connect 100Base-TX twisted-pair copper cables to 100Base- FX fiber optic cables and are PCI (Peripheral Component Interconnect) powered.
-
Page 2: Installation
E-100BTX-FX-N-01 / E-100BTX-FX-NLP-01 Installation Installation RJ-45 port -- Continued on the network interface card (NIC) CAUTION: Wear a grounding device and observe electrostatic discharge Install the Copper Cable precautions when setting the 4-position switch. Failure to observe this caution Use the enclosed 100Base-TX compliant could result in damage to, and failure of, the media converter. -
Page 3: Operation
E-100BTX-FX-N-01 / E-100BTX-FX-NLP-01 Operation Operation -- Continued Pause Control Frame LED Indicators The pause feature is used to temporarily suspend data transmission in order to Use the status LEDs to monitor the media converter operation in the network. relieve buffer congestion. If a media converter needs some time to clear network congestion, it will send a pause signal to the media converter at the FX LED on = The fiber link has been established. -
Page 4: Fiber Cable
E-100BTX-FX-N-01 / E-100BTX-FX-NLP-01 Cable Specifications Troubleshooting -- Continued The physical characteristics must meet or exceed IEEE 802.3™ specifications. Are both FX and TX LEDs illuminated? Fiber Cable • Confirm that the media converter is properly inserted into the PC Bit Error Rate: <10-9 workstation or the file server. -
Page 5: Compliance Information
Compliance Information E-100BTX-FX-NLP-01(xx): CISPR22/EN55022 Class A; CE Mark E-100BTX-FX-N-01(xx): CISPR22/EN55022 Class A + EN55024; CE Mark FCC Regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
