Manageable
Media Conversion
Center
33035.G
E-MCC-1600
For assistance in installing, using, or
maintaining the TRANSITION Networks
Media Conversion Center, contact
TRANSITION Networks Technical
Support at:
(800) 260-1312
or contact your local distributor.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-MCC-1600 and is the answer not in the manual?

Questions and answers

Related Manuals for Transition Networks E-MCC-1600

Summary of Contents for Transition Networks E-MCC-1600

  • Page 1 Manageable Media Conversion Center 33035.G E-MCC-1600 For assistance in installing, using, or maintaining the TRANSITION Networks Media Conversion Center, contact TRANSITION Networks Technical Support at: (800) 260-1312 or contact your local distributor.

  • Page 2: Compliance Information

    CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in damage to the public telephone network. Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer Konformität.

  • Page 3: Table Of Contents

    Installing Optional AC Power Supply Module in Media Conversion Center Chassis ..... . 3.3 Installing Optional 48 VDC Power Supply Module in Media Conversion Center Chassis .
  • Page 4 Fault Isolation and Recovery ....5.2 5.1.1 At the Remote Network Managment Station 5.2 5.1.2 At the Chassis Front or Back ..4.10 .
  • Page 5 Appendix C. Introduction to SNMP in the E-MCC-1600 ..C.1 Appendix D. Displaying the E-MCC-1600 MIB Tree ..D.1 Displaying MIB Variables ....D.1 Displaying the Entire MIB Tree .

  • Page 7: Preface

    Preface This user’s guide is intended for the network administrator responsible for installing, configuring, using, and maintaining a Transition Networks 16-Slot Media Conversion Center. A working knowledge of local area network (LAN) operations, including familiarity with communications protocols used on interconnected LANs, is assumed. 16-SLOT MEDIA CONVERSION CENTER...

  • Page 9: Introduction

    INTRODUCTION The modular Transition Networks E-MCC-1600 16-Slot Media Conversion Center allows the network administrator to select from among Transition Networks Media Converter Slide-in-Modules, to install the Media Converter Slide-in-Modules in the Media Conversion Center chassis, and then to connect various network media, at a central wiring location, through the Media Converter Slide-in-Modules.

  • Page 10: The Media Conversion Center

    The Media Conversion Center The Transition Networks 16-Slot Media Conversion Center chassis provides installation space for up to sixteen Media Converter Slide-in- Modules, up to two Power Supply Modules, and one SNMP Management Module, as shown in the cut-out top view below: NOTE: Media Converter Slide-in-Modules, Power Supply Modules, and Management Modules are all hot-swapable.

  • Page 11: Media Converter Slide-In-Modules

    Power In Use Management Module Power Link E-MCC-1600 NOTE: Refer to the documentation that comes with each Media Converter Slide-in-Module for connector and LED indicator information specific to that Media Converter Slide-in-Module. Power Supply Module Power Supply Module An AC Power Supply Module, installed at the back of the Media...

  • Page 12: Connectors, Indicators, And Switches

    LEDs located on the front of the Media Conversion Center. Power LED ON/OFF Switch Fuse AC Power Connector Serial port Ethernet port Reset Switch ON/OFF Switch Fuse Media Conversion Center Power Modules Power In Use Power In Use Management Module Power Link E-MCC-1600 E-MCC-1600...

  • Page 13: The Media Conversion Center In The Network

    The Media Conversion Center in the Network Using Media Converter Slide-in-Modules installed in the 16-Slot Media Conversion Center, the network administrator can connect various network media at a central wiring location As new media are added to the network, the network administrator can install new Media Converter Slide-in-Modules to support the changed network requirements.

  • Page 14: Optional Network Management (Continued)

    CLI Access via Telnet CLI Access via Telnet is useful when CLI access is desired from a physical location other than the wiring closet where the E-MCC-1600 is installed. Any standard Telnet client (such as the one that is included with Windows 95) can be used from any location on the network.
  • Page 15 1 INTRODUCTION Telnet Security: The Telnet password is the same as the private community name. This is so because the authority granted to the Telnet CLI is not significantly more than that provided by the “private” (i.e. most priveleged) MIB view. Note that network traffic carried by the devices installed at the front of the Conversion Center can not be disturbed even through the most priveleged access to the Management Module.

  • Page 17: Site Planning

    SITE PLANNING The site for the 16-Slot Media Conversion Center must provide the following: • Power outlet for each Power Supply Module in the 16-Slot Media Conversion Center • Adequate ventilation • Standard environmental conditions • Isolation from electrical noise, including radio transmitters and broadband amplifiers, motors, high power electrical lines, or fluorescent light fixtures.

  • Page 19: Installation

    3.10 3.11 3.12 16-SLOT MEDIA CONVERSION CENTER Unpacking E-MCC-1600 Equipment ...3.2 Installing Optional AC Power Supply Module in Media Conversion Center Chassis ...3.3 Installing Optional 48 VDC Power Supply Module in Media Conversion Center Chassis ...3.6 Installing Optional Management Module in Media Conversion Center Chassis ...3.9...

  • Page 20: Unpacking E-Mcc-1600 Equipment

    Unpacking E-MCC-1600 Equipment Use the following list to verify the shipment: Item 16-Slot Media Conversion Center: Power Cord User’s Guide 48 VDC Power Supply Module Redundant AC Power Supply Module Management Module Transition Networks TN-View SNMP software One or more selectable...

  • Page 21: Installing Optional Ac Power Supply Module In Media Conversion Center Chassis

    (master) Power Supply Module OR as the secondary (slave) Power Supply Module. If any Power Supply Module without a Master/Slave switch is installed in the E-MCC-1600 chassis, by default that Power Supply Module is secondary (slave). If neither Power Supply Module has a Master/Slave switch, primary/secondary status is automatic and non-configurable.
  • Page 22 NOTE: If Master/Slave switch is installed on ANY Power Supply Module installed in chassis, ensure that at least one Power Supply Module in the E-MCC-1600 chassis is configured as the primary (master) Power Supply Module. Set Master/Slave switch, if necessary.
  • Page 23 Center installation slot, aligning Power Supply Module with installation guides. NOTE: Ensure that the Power Supply Module is firmly seated against the chassis backplane. Carefully install two (2) screws (retained in Step 2) through Power Supply Module into Media Conversion Center, rotating clockwise to secure.

  • Page 24: Installing Optional 48 Vdc Power Supply Module In Media Conversion Center Chassis

    (master) Power Supply Module or as the secondary (slave) Power Supply Module. If any Power Supply Module without a Master/Slave switch is installed in the E-MCC-1600 chassis, by default that Power Supply Module is secondary (slave). If neither Power Supply Module has a Master/Slave switch, primary/secondary status is automatic and non-configurable.
  • Page 25 NOTE: If Master/Slave switch is installed on any Power Supply Module installed in chassis, ensure that at least one Power Supply Module in the E-MCC-1600 chassis is configured as the primary (master) Power Supply Module. Set Master/Slave switch, if necessary.
  • Page 26 Remove Power Supply Module protective plate from installation slot by removing and retaining two (2) screws that secure protective plate to back of Media Conversion Center chassis. Carefully slide 48V Power Supply Module into Media Conversion Center installation slot, aligning Power Supply Module with installation guides.

  • Page 27: Installing Optional Management Module In Media Conversion Center Chassis

    Management Module. To install the Management Module in the E-MCC-1600 chassis: 16-SLOT MEDIA CONVERSION CENTER Carefully place E-MCC-1600 on table or other flat, stable surface. Locate Management Module installation slot on back of E-MCC- 1600.

  • Page 28: Installing Media Converter Slide-In-Module(S) In Media Conversion Center Chassis

    Slide-in-Module(s). To install the Media Converter Slide-in-Module in the E-MCC-1600 chassis: 3.10 Carefully place the E-MCC-1600 on table or other flat, stable surface. Locate sixteen (16) Media Converter Slide-in-Module installation slots at the front of the E-MCC-1600. NOTE: Media Converter Slide-in-Modules can be installed in any installation slot, in any order.

  • Page 29: Table-Top Installation

    (4) universal mounting bracket installation holes and so that bracket surface to be attached to 19- inch site rack is flush with front of chassis. Using Phillips screwdriver, install three (3) screws through mounting bracket into side of 16-Slot Media Conversion Center.

  • Page 30: Optionally Connecting Management Module To Terminal Or Terminal Emulator

    Attach the other end of the DB9 serial port cable to an ASCII terminal or terminal emulator. baud stop bits data bits parity 3 INSTALLATION Attached Terminal or Terminal Emulator connected to DB-9 serial port via null modem cable 9600 NONE E-MCC-1600...

  • Page 31: Powering The Media Conversion Center

    “-”. Turn terminal screw clockwise to secure. Connect ground terminal to Media Conversion Center terminal block control marked “chassis ground”. Turn terminal screw clockwise to secure. Set 48 VDC Power Supply Module power switch to “I”. Verify that Media Conversion Center is powered by observing illuminated Power LED and fan operation.

  • Page 32: Optionally Using Attached Terminal Interface To Set Ip Parameters

    Conversion Center and the Media Conversion Center has been powered (or reset), a command-line prompt comes up at the attached terminal or terminal emulator: E-MCC-1600> NOTE: The console prompt string is determined by the MIB variable mib2.system.sysName.0. The default value for this MIB variable is , as shown here.

  • Page 33: Optionally Configuring Telnet And Telnet Security

    3.11 Optionally Configuring Telnet and Telnet Security The MCC-1600 management module's command line interface can be accessed through a Telnet server. Any standard character-mode (preferred) or line-mode Telnet client can be used to access the command line interface from any station not blocked by network security. The Management Module's TCP uses the Telnet Remote IP address and the Telnet Remote IP address mask to validate incoming connection requests: To permit Telnet connections from only a single location on the network...

  • Page 34: Optionally Configuring Snmp Traps

    NOTE: The default value is 1.0 seconds. Use the TM= (TRACE MASK) command to cause trap conditions to be reported to the command-line interface by setting the appropriate bit in the system trace mask. E-MCC-1600...

  • Page 35: Operation

    OPERATION Daily operation of the Transition Networks E-MCC-1600 16-Slot Media Conversion Center requires no network administrator activity except occasionally monitoring physical status LED indicators on the 16-Slot Media Conversion Center and on installed Media Converter Slide-In-Modules to monitor an unmanaged 16-Slot Media Conversion Center.

  • Page 36: Using Status Leds

    Converter Slide-In-Module to interpret the LED indicators for that module. Media Conversion Center Power Modules Power In Use Power In Use Management Module Power Link E-MCC-1600 Media Conversion Center Power Modules Power In Use Power In Use Management Module Power Link...

  • Page 37: Using Management Module Command-Line Interface (Cli)

    Using Management Module Command-line Interface (CLI) The Media Conversion Center Management Module command-line interface (CLI), analogous to a Unix shell and accesed from an attached terminal or from a remote Telnet location, permits the network administrator to display status messages and to display and to alter various network settings.

  • Page 38: At A Telnet Connection

    NOTE: The password is the same as the private community name. If an incorrect password is entered, the server immediately aborts the client's connection. Transition Networks Telnet Server System name: E-MCC-1600 Press CTRL-D to disconnect. Enter password: Remote console connected to nnn.nnn.nnn.nnn.

  • Page 39: Command-Line Interface Commands

    4.2.3 Command-line Interface Commands The Media Conversion Center Management Module command-line interface (CLI) is analogous to a UNIX shell. NOTE: In most cases, a “brief” Internet Protocol (IP) address format is supported: If only the last octet of an IP address is specified, the other three octets are filled in automatically (based on the assumption that the new address is on the same subnet as the local IP address).
  • Page 40 (1 second). Specifying an interval of 0 seconds cancels rping. This command saves many of the parameters set by the other commands in this section to FLASH memory. Once saved, the settings persist E-MCC-1600...
  • Page 41 set=oid,type,value set gateway= set ip= set netmask= set private=private community name set public=public community name set tntrip=nnn.nnn.nnn.nnn set tntripmask=nnn.nnn.nnn.nnn 16-SLOT MEDIA CONVERSION CENTER through rebooting and power cycling. Saved settings can be overwritten at any time by issuing another save command. Performs an SNMP SET operation on the local MIB database, using the given OID, type and value.
  • Page 42 CAUTION: Using this command may seriously degrade system performance.: The mask is always entered and displayed in hex, and is the combination of all of the currently selected traces - each represented by a E-MCC-1600...
  • Page 43 Management Module. CAUTION: If the 'write' phase is interrupted or fails for any reason, the E-MCC-1600 Management Module will be damaged and will require servicing from Transition Networks. Using a battery-backed uninterrupt- ible power supply is highly recommended.

  • Page 44: Command-Line Interface Messages

    This message is a response to a console command. You have entered a privileged command without first entering super-user mode. The privileged command is rejected. Enter “SU=” followed by the private community name, and then re-enter the command that caused the error. 4.10 E-MCC-1600...
  • Page 45 Community name changed. Use SAVE command to make permanent. This message is a response to a console command. The public or private community name was changed via the “PUBLIC=new-public” or “PRIVATE=new- private” commands. This message warns you that the changes made will be lost the next time the Management Module is reset, rebooted, or power cycled - unless they are saved in FLASH memory as suggested.
  • Page 46 NOTE: Many terminal emulator implementations use XMODEM/CRC but describe it as “XMODEM.” 3) Is the transmitting station fast enough? Place the code on a local hard disk and use that copy as the source for your XMODEM/CRC transfer. 4.12 E-MCC-1600...
  • Page 47 DOWNLOAD: XMODEM/CRC receive success, nnn bytes! DOWNLOAD: FLASH ‘WRITE’ phase beginning. DO NOT INTERRUPT! This message is a response to the “xr” console command. The XMODEM/CRC transfer was successful. This message is your “last chance” to abort the firmware update operation. When this message is displayed, you have approximately seven seconds left before the write begins (assuming that your terminal emulator displays it immediately when it is transmitted).
  • Page 48 This message is a response to a console command. This message indicates a latent software defect. Call Transition Networks for assistance. FLASH: ROM starting address is not on sector boundary. This message is a response to a console command. This message indicates a latent software defect. Call Transition Networks for assistance. 4.14 E-MCC-1600...
  • Page 49 FLASH: Saving configuration, please wait up to one minute... This message is a response to a console command. The Management Module is saving its configuration to flash (i.e. non-volatile) memory. If this operation is interrupted, the saved configuration will be invalid and the Management Module will be unable to access the network (e.g.
  • Page 50 Module and the networking code in the named station. If the message persists, call Transition Networks for assistance. This message is printed only when the appropriate traces are enabled via the “TM=mask” command. For more information, see RFC 792, Internet Control Message Protocol, available via anonymous FTP from NIC.DDN.MIL. 4.16 E-MCC-1600...
  • Page 51 ICMP: REDIRECT message received from nnn.nnn.nnn.nnn (ignored) ICMP: code=ttttt recommended gateway=nnn.nnn.nnn.nnn Where ttttt is “REDIRECT for NETWORK”, “REDIRECT for HOST”, or “REDIRECT for NETWORK and TOS”. This unsolicited message is displayed in response to a packet that arrived at the Ethernet interface.
  • Page 52 RFC collection, available via anonymous FTP from NIC.DDN.MIL. Illegal character This message is a response to a console command. A non-printable character (outside the range 20h to 7Eh) was seen in a community name entered from the console. 4.18 E-MCC-1600...
  • Page 53 llegal length. 1-30 characters required. This message is a response to a console command. Re-enter the console command, making sure that the community name entered falls within the given bounds. No white space is permitted anywhere in the command. Illegal register read nnnn nnnn nnnn Illegal register write nnnn nnnn nnnn This unsolicited message is displayed when an unusual hardware or software condition is detected.
  • Page 54 Management Module will attempt to locate the destination station on the local Ethernet segment without using a gateway - this process almost always fails. This message is printed when any traces (including the default traces) are enabled via the “TM=mask” command. 4.20 E-MCC-1600...
  • Page 55 Once the settings have been proven to work, they should be saved to non-volatile memory via the “SAVE” command. E-MCC-1600> This is a prompt that indicates that the Management Module’s command line interface is ready for another non-privileged command. To enter privileged commands, first enter the “SU=private”...
  • Page 56 1c) excessive broadcast traffic on the network segment. 2) Memory depletion due to excessive console output traffic Or, 3) a latent software defect or hardware failure. To eliminate these messages, use the “TM=mask” command to disable the traces. 4.22 E-MCC-1600...
  • Page 57 RTL ISR=nn This is an advanced debug message that should only be displayed when debug traces have been enabled at the advice of Transition Networks technical support. The Ethernet controller caused an interrupt. Additional normal-completion indications may follow: “[Remote DMA complete]” “[TX ok]” “[RX ok]” “<get: b=nn-c=nn>”.
  • Page 58 SNMP: Community is not OCTET STRING in request from nnn.nnn.nnn.nnn This unsolicited message is displayed in response to a packet that arrived at the Ethernet interface. This message indicates an malformed incoming PDU. If the message persists, call Transition Networks for assistance. 4.24 E-MCC-1600...
  • Page 59 SNMP: Decode of incoming PDU failed This unsolicited message is displayed in response to a packet that arrived at the Ethernet interface. A variety of causes are possible, e.g. malformed SNMP message, out of memory, etc. Usually, this message is accompanied by other more specific messages, if the appropriate traces are enabled.
  • Page 60 This message indicates a latent software defect or a hardware defect. Power cycle the management module. If message persists, contact Transition Networks for assistance. SNMP: Internal error, invalid MIB structure This is a system startup message. This message indicates a latent software defect. Call Transition Networks for assistance. 4.26 E-MCC-1600...
  • Page 61 "POWER SUPPLY STATUS CHANGE" trap has been transmitted. It is normal for this message to be displayed during system startup if the chassis lacks its normal complement of two power supplies. This message is printed only when the appropriate traces are enabled via the "TM=mask"...
  • Page 62 SNMP: Trap polling is now enabled. This message indicates that the user has successfully enabled trap polling. As a result, the trap detection system has been re-initialized and the chassis slots are now being examined for new trap conditions. See also "SNMP: Warning: SNMP traps are disabled until..."...
  • Page 63 [su] E-MCC-1600> This is a prompt that indicates that the Management Module’s command line interface is ready for another super-user command. To return to non-privileged mode, enter the “SU” command. NOTE: The console prompt string is determined by the MIB variable mib2.system.sysName.
  • Page 64 Telnet security configuration is changed. An active session is terminated when the remote client actively disconnects from the management module's Telnet server, when the server is unable to contact the client, or when the LOGOFF command is entered. 4.30 E-MCC-1600...
  • Page 65 TRANSMIT TIMEOUT This unsolicited message is displayed when an unusual hardware or software condition is detected. The Ethernet controller did not confirm completion of a transmit command. This may indicate a hardware failure. Power cycle the Management Module. If the message persists, call Transition Networks for assistance.
  • Page 66 IP address, and a subnet mask that are compatible, and enter them into the system via the “SET IP=ip”, “SET GATEWAY=ip”, and/or “SET NETMASK=mask” commands, then enter the “SAVE” command to make the changes permanent. 4.32 E-MCC-1600...
  • Page 67 WARNING: Saved configuration settings missing or corrupt. This is a system startup message. This message is normal on a new Management Module or (sometimes) on a Management Module whose firmware has been updated. When this message appears, the Management Module’s network interface is disabled.

  • Page 68: 4.2.5 Command-Line Interface Trace Masks

    NOTE: When the console output queue (which holds roughly 30 lines of text by default) is full, new console messages are discarded without notice. E-MCC-1600 4.34...

  • Page 69: 6Traps

    Indicates that one of the unit's redundant power supplies either has become active or has become inactive. ERROR (defined in E-MCC-1600.MIB) Indicates that a monitored entity was 'operational' the previous time it was checked, and is currently either 'down' or 'non-existent.'...

  • Page 70: Using Remote Snmp

    The Management Module supports the standard SNMP protocol, which means that any SNMP-compliant NMS can be used to monitor the E-MCC-1600 and installed Slide-In-Modules. Please see your reseller for a copy of TN-View, a software package that allows the Media Conversion Center to be displayed graphically.

  • Page 71: Maintenance

    16-SLOT MEDIA CONVERSION CENTER Fault Isolation and Recovery ...5.2 5.1.1 At the Remote Network Managment Station ...5.2 5.1.2 At the Chassis Front or Back ...5.4 Hardware Replacement Procedures ...5.6 5.2.1 Replacing Media Converter Slide-In-Module ..5.6 5.2.2 Replacing Fuse on Standard Power Supply Module ...5.7...

  • Page 72: Fault Isolation And Recovery

    If the addresses do NOT match, refer to documentation for the DNS server, the SNMP management application at the NMS, and/or the Media Conversion Center Management Module for direction for modifying the addresses to correct the discrepancy. Determine if the NMS can PING the Media Conversion Center E-MCC-1600...
  • Page 73 • • 16-SLOT MEDIA CONVERSION CENTER 5 MAINTENANCE Management Module. Refer to documentation for the SNMP management application for direction for entering the PING command and specifying the DNS name of the Media Conversion Center Management Module. If the PING is successful, SNMP traffic may be blocked by a router or firewall or the fault may be in the SNMP management application.

  • Page 74: At The Chassis Front Or Back

    Transition Networks technical support. Verify that the Management Module power indicators on the front of the chassis and on the back of the Management Module are illuminated installed at the rear of the Media Conversion Center. Failure may indicate: •...
  • Page 75 Determine if the Media Conversion Center Management Module is connected to an active 10BASE-T Ethernet port. 16-SLOT MEDIA CONVERSION CENTER 5 MAINTENANCE NOTE: On a network that is too quiet, this test will not be possible. The RX LED indicator should blink every time a network broadcast is transmitted.

  • Page 76: Hardware Replacement Procedures

    Media Converter Slide-in-Module(s). NOTE: The Media Converter Slide-in-Modules are hot-swappable. To replace a Media Converter Slide-in-Module in the E-MCC-1600 chassis: Remove Media Converter Slide-in-Module to be replaced by rotating and removing one (1) screw that secures Slide-in-Module to E-MCC-1600 chassis front and sliding Media Converter Slide- In-Module from E-MCC-1600 chassis.

  • Page 77: Module

    5.2.2 Replacing Fuse on Standard Power Supply Module CAUTION: Replace fuse only with same size and rating. Failure to observe this caution could result in equipment damage. To replace a Power Supply Module fuse: 16-SLOT MEDIA CONVERSION CENTER Disconnect outlet end of power cord from AC wall socket. At Media Conversion Center back, disconnect power cord from Power Supply Module power receptacle.

  • Page 78: Replacing Standard Power Supply Module

    Conversion Center. Failure to observe this caution could result in damage to, and subsequent failure of, the Power Supply Module. To replace a Power Supply Module in the E-MCC-1600 chassis: Remove Faulty Power Supply Module from Chassis Disconnect outlet end of power cord from AC wall socket.

  • Page 79: Connect To Power

    NOTE: If Master/Slave switch is installed on ANY Power Supply Module installed in chassis, ensure that at least one Power Supply Module in the E-MCC-1600 chassis is configured as the primary (master) Power Supply Module. Set Master/Slave switch, if necessary.

  • Page 80: Replacing 48V Power Supply Module

    Conversion Center. Failure to observe this caution could result in damage to, and subsequent failure of, the Power Supply Module. To replace a Power Supply Module in the E-MCC-1600 chassis: Remove Faulty Power Supply Module from Chassis Set 48 VDC Power Supply Module power switch to “0”.
  • Page 81 NOTE: Ensure that the Power Supply Module is firmly seated against the chassis backplane. Carefully install two (2) retained screws through Power Supply Module into Media Conversion Center chassis, rotating clockwise to secure. Connect +48 VDC terminal to Media Conversion Center terminal block control marked “+”.

  • Page 82: Replacing Management Module

    E-MCC-1600 chassis: At Media Conversion Center back, remove Management Module to be replaced by removing two screws that secure Management Module to back of E-MCC-1600 and sliding Management Module from E-MCC-1600 chassis. NOTE: Retain screws for installing replacement Management Module.

  • Page 83: Firmware Upgrades

    Firmware Upgrades CAUTION: The MCC-1600 software cannot check to ensure that the firmware is compatible with installed hardware. Incorrect firmware downloads WILL damage the Management Module, NECESSITATING FACTORY SERVICE. If in doubt, abort the upgrade and contact Transition Networks Technical Support for assistance. CAUTION: If the 'WRITE' phase is interrupted or fails for any reason, the Management Module will be damaged, NECESSITATING FACTORY SERVICE.

  • Page 85: Appendix A. E-Mcc-1600 Technical Specifications

    E-MCC-1600 Regulation: EMC Directive 89/336/EEC Purpose: To declare that the E-MCC-1600 to which this declaration refers is in conformity with the following standards. EMC-CISPR 22: 1985 Class A; EN 55022: 1988 Class A; EN 50082-1:1992; EN 60950 A4:1997; IEC 801.2, IEC 801.3, and IEC 801.4; IEC 950 I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s).

  • Page 87: Appendix B. Null Modem Cable Specifications

    Appendix B. Null Modem Cable Specifications The DD9 cable is used for connecting a terminal or terminal emulator to the Media Conversion Center Management Module to access the command-line interface. The table below shows the pin assignments for the DB9 cable. Function Carrier Detect Receive Data...

  • Page 89: Appendix C. Introduction To Snmp In The E-Mcc-1600

    NMS. Managed objects can be scalar (a single object instance – such as the E-MCC-1600 network IP address) or tabular (related instances – such as the various LED displays on a Media Converter Module installed in the E-MCC-1600).
  • Page 90 Vendors define private branches to include instances of their products. Transition Networks' private MIB is represented by the object identifier 1.3.6.1.4.1.868 and includes objects such as "chassis" (for the E-MCC-1600), identified in ASN.1 notation by OID 1.3.6.1.4.1.868.2.4 with the associated label "mcc16ComIpAddr" (the E-MCC-1600 IP address), which is identified in ASN.1 notation by OID 1.3.6.1.4.1.868.2.4.2.1.1.4.

  • Page 91: Appendix D. Displaying The E-Mcc-1600 Mib Tree

    Appendix D. Displaying the E-MCC-1600 MIB Tree Some users find it helpful to have access to a list of the MIB variables that are supported by the E-MCC-1600’s SNMP agent (for example when formulating specialized SNMP queries or when attempting to determine whether or not the firmware in the agent contains support for a new device).
  • Page 92 Super-user mode on. [su] MCC16> sql=20000 Serial queue limit changed from 2000 to 20000 bytes [su] MCC16> ?=. (the MIB is displayed here) [su] MCC16> sql=20000 Serial queue limit changed from 20000 to 2000 bytes [su] MCC16> su Super-user mode off. E-MCC-1600...

  • Page 93: Appendix E. Snmp Glossary

    Appendix E. SNMP GLOSSARY binding flash ICMP Object Id getnext Protocol SNMP 16-SLOT MEDIA CONVERSION CENTER Address Resolution Protocol Method for determining Ethernet address from IP address. See ‘variable binding.’ Memory that retains its contents when power is disconnected. Management Information Base. The types, names, and OID tree structure of a group of SNMP variables.
  • Page 94 IP. A subsection of a PDU. A variable binding contains an Object ID and the data value associated with that Object ID. A protocol commonly used to transfer files across an RS-232 link. E-MCC-1600...
  • Page 95 Configuring Telnet Security 3.15 Configuring Traps 3.16 Connecting Media Converter Slide-In- Modules to Network 3.12 Installing Media Converter Slide-in- Module(s) 3.10 Installing the E-MCC-1600 in Rack or on Table Rack Installation 3.11 16-SLOT MEDIA CONVERSION CENTER Optionally Installing Management Module 3.9 Powering the Media Conversion Center 3.13...
  • Page 96 Specifications, Power Input A.1 Status LEDs 4.2 Telnet Security 1.7, 3.15 Telnet, Optionally Configuring 3.15 Traps, Optionally Configuring 3.15, 3.16 Using SNMP at Command-Line Interface Through an Attached Terminal 4.3 Through Telnet Connection 4.4 xr, Using for firmware Upgrades 5.13 E-MCC-1600...
