Kit Description

Products

Kit Parts List

RM2000B Rackmount Kit
The RM2000B rackmount is designed for use with TDS1000B, TDS1000C-EDU,
TDS2000B, and TDS2000C series oscilloscopes.
TDS1000B and TDS1000C-EDU Series
TDS2000B and TDS2000C Series
NOTE.
This kit is suitable only for TDS1000B, TDS1000C-EDU, TDS2000B, and
TDS2000C oscilloscopes. Do NOT use this kit for TDS1000 or TDS2000 models.

Table 1: Kit parts list

Circuit/
figure
Number Quantity Part number
1-1 1 each RM2000B
-2 1 each 071-1984-xx
-3 1 each 016-1978-xx
–
4 each
–
4 each
–
4 each
All serial numbers
All serial numbers
Description
RM2000B Rackmount kit, includes a
front and back panel set, 2 handles,
instructions, bag of screws
RM2000B Rackmount kit instructions,
English (this document)
Standard mounting hardware in plastic
bag includes:
(for handles) screw 8-32 x 1/2 phil pan
(for handles) #8 med spit L/W
screw 10-32 x 3/4 poz
3
