Kit Description
4

Table 1: Kit parts list, (cont.)

Circuit/
figure
Number Quantity Part number
–
4 each
–
4 each
–
4 each
–
4 each
–
4 each
–
4 each
To install a TDS1000B, TDS1000C-EDU, TDS2000B or TDS2000C series
instrument, refer to the following illustration.
Figure 1: RM2000B Rackmount assembly
Figure 2: Dimensions of the RM2000B Rackmount
Description
screw 12-24 x 3/4 poz
screw M5 x 16 oval head phil
screw M6 x 16 oval head phil
flat washer (M5 and #10 screws)
flat washer (M6 and #12 screws)
#10 finish washer
RM2000B Rackmount Kit
