Kit Description

Products

Kit Parts List

Table 1: Kit parts list
Circuit/figure
number Quantity
1-1 1 each
-2 1 each
-3 1 each
-4 1 each
-5
1 each
-6 2 each
Not shown 1 each
Not shown 1 each
Not shown 4 each
Not shown 4 each
Not shown 4 each
Not shown 4 each
Not shown 4 each
Not shown 14 each
RMD2000 Rackmount Kit
This introduction describes the rackmount kit for your standard bench-top
instrument.
The rackmount kit is a collection of parts that, once installed, configure the
instrument for mounting into a standard 19-inch equipment rack.
DPO2000 Series
MSO2000 Series
NOTE.
The hardware set included in this kit is also used with other kits. Not all of
the hardware will be needed.
Part number Description
407-5315-xx BRACKET, BOTTOM
426-2632-xx FACEPLATE, FRONT BRACKET
407-5318-xx BRACKET, LEFT SIDE
407-5317-xx BRACKET, RIGHT SIDE
407-5316-xx BRACKET, TOP
367-0450-xx HANDLE, BOW; CARRYING, 3.75 CTR, 8-32 THD 1.75 H, TG2000,
SAFETY CONTROLLED
071-2332-00 INSTRUCTIONS, TECH:RACKMOUNT, ENGLISH; RMD2000 (this
document)
016-2006-xx
KIT, HARDWARE RMD2000 — Includes the bow handles (above) and all
the following:
210-0833-xx WASHER, RECESSED; 0.42 ID X 0.112 THK, STL NI PLATED, 0.588 OD
210-1061-xx WASHER, FLAT; 0.203 ID X 0.625 OD X 0.062, 410 SS, PASSIVATE
210-1546-xx SCREW, MACHINE, PAN, 8-32 X 1/2 PHIL, SST
210-1547-xx LOCKWASHER, #8, SPLIT, .040 THICK
210-1548-xx WASHER, FLAT, 12 mm OD X 6.4 mm ID X 1.6 mm THK, STAINLESS
STEEL
211-0507-xx
SCREW, MACHINE; 6-32 X 0.312, PNH, 410 SS PASSIVATED, POZ
All serial numbers
All serial numbers
