Kit Description

Products
Kit Parts List
SPG600 Sync Pulse Generator Rackmount Instructions
This document describes how to install the rackmount kit onto your SPG600
Sync Pulse Generator.
The rackmount kit is a collection of parts that, once installed, configures the
instrument for mounting into a standard 19-inch equipment rack.
This document supports Tektronix modifications ECR31439 and ECR31689.
SPG600
All serial numbers
Figure 1 on
page 2
Quantity
1-1 1 ea
1-2 8 ea
1-3 1 ea
1-3 8 ea
1-3 6 ea
1-3 6 ea
- - - - - - 1 ea
NS - Not Saleable
Part number Description
351-0104-xx Guide rack, consisting of: left and right sides
212-A041-xx Screw, mach: M4 x 8 mm, Phillips
351-0751-01 Track, slide-out sections: pair (LH, RH)
NS Screw, mach: 10-32, panhead, 3/8 in, Phillips
NS Screw, mach: M6 x 10 mm, slotted
NS Bar nut
075-0800-01 Technical manual: Instructions, SPG600
Rackmount kit
1
