Configuration
#> defaultopmode on
Success.
5. Turn Opmode ON.
#> opmode on
Success.
.

Remote Unit Configuration

Configure the RU in the same manner as the MU. Since the default unit type (utype) is RU, you do not need to set this
parameter.
1. Set the Peer ID with the MAC address of the MU. Only use the last 8 digits of the MAC address.
#> peerid de
Success.
#>
2. Set channel and polarization. (in this example set the channel to 2 and polarization to H).
#> freq 2 h
Ch# 2 h (5280 MHz)
Success.
3. Set default Opmode to "ON."
#> defaultopmode on
Success.
4. Turn Opmode "ON."
#> opmode on
Success.

Establishing a Wireless Link

If the MU and RU are properly configured and in opmode "ON", the two radios will automatically begin the
authentication process and become connected. To determine if the two radios are connected, type the sysinfo 2
command.
Example:
#> sysinfo 2
********************************* 2 *********************************
[Opmode] on [Default Opmode] on
[Active Channel] 2 h [Freq] 5280 MHz
[Speed] 36 Mbps [Tx Power] 7 dBm [Power Range] -4..7 dBm
[Peer ID] DE1B784B
[Peer IP Config] 10.254.1.3 255.255.255.248 10.254.1.1
Success.
#>
The [status] field indicates whether the MU and RU are connected or disconnected. If connected, the MU and RU will
automatically start passing Ethernet traffic over the wireless link.

Changing IP Address

Use the ipconfig command to change the radio's ip address, subnet mask and gateway.
Trango Broadband Wireless — Atlas5010
1B7842
[Status] connected
[RSSI] -75 dBm
page 17
