Overview

Range vs. Throughput

The following table shows approximate maximum ranges (at recommended fade margins) achievable with the
system using various antenna configurations. Longer ranges are achievable, but will result in lower fade margins. To
estimate theoretical throughput and fade margin for any distance, download the link budget / fade margin calculator tool
from www.trangobroadband.com .
ISM (5725 MHz to 5875 MHz) Line-of-Sight Range & Throughput
Antenna
Integrated 23 dBi
15" Flat Panel
External 27 dBi
2' Dish
External 30 dBi
3' Dish
External 34 dBi
4' Dish
U-NII (5470 MHz to 5725 MHz & 5250 MHz to 5350 MHz) Line-of-Sight Range & Throughput
Antenna
Integrated 23 dBi
15" Flat Panel
External 27 dBi
2' Dish
External 30 dBi
3' Dish
External 34 dBi
4' Dish
Trango Broadband Wireless — Atlas5010
5 miles
45 Mbps
(10 db fade margin)
45 Mbps
(18 db fade margin)
45 Mbps
(24 db fade margin)
45 Mbps
(30 db fade margin)
6 miles
20 Mbps
(10 db fade margin)
31 Mbps
(11 db fade margin)
31 Mbps
(14 db fade margin)
45 Mbps
(10 db fade margin)
20 miles
11 Mbps
(14 db fade margin)
20 Mbps
(18 db fade margin)
26 Mbps
(20 db fade margin)
32 Mbps
(20 db fade margin)
10 miles
11Mbps
(12 db fade margin)
20 Mbps
(10 db fade margin)
20 Mbps
(13 db fade margin)
30 Mbps
(13 db fade margin)
Atlas5010
30 miles
6 Mbps
(17 db fade margin)
10 Mbps
(20 db fade margin)
18 Mbps
(22 db fade margin)
30 Mbps
(15 db fade margin)
15 miles
6Mbps
(9 db fade margin)
11Mbps
(12 db fade margin)
16Mbps
(12 db fade margin)
20Mbps
(14 db fade margin)
page 7
