SNMP

Chapter 5 SNMP

The Atlas supports SNMP (Simple Network Management Protocol). Network management consists of the following 3
categories: configuration, Link and Association monitoring and Alarms. Besides this proprietary Management
Information Base (MIB) the Atlas also supports a large part of the MIB-II OIDs.
Review the Trango MIB (TRANGO-P5M-MIB.mib) available on our website for the complete listing of all MIB objects
available.
These capabilities allow the system administrator to provide superior service through higher network accessibility and
integrated performance monitoring.
Depending on your Network Node Manager (NNM) it may be necessary to append a ".0" onto the end of each of the
OIDs listed below for proper operation.
Objects for Configuration
1.3.6.1.4.1.5454.1.40.1.1.1
1.3.6.1.4.1.5454.1.40.1.8.3
1.3.6.1.4.1.5454.1.40.1.3
1.3.6.1.4.1.5454.1.40.1.4
1.3.6.1.4.1.5454.1.40.1.5
1.3.6.1.4.1.5454.1.40.1.13.1
1.3.6.1.4.1.5454.1.40.1.13.2
1.3.6.1.4.1.5454.1.40.1.13.3
1.3.6.1.4.1.5454.1.40.1.13.4
1.3.6.1.4.1.5454.1.40.2.1
1.3.6.1.4.1.5454.1.40.2.2
1.3.6.1.4.1.5454.1.40.2.3
1.3.6.1.4.1.5454.1.40.2.4
1.3.6.1.4.1.5454.1.40.2.5
1.3.6.1.4.1.5454.1.40.1.14
Objects for Link and Association Monitoring
1.3.6.1.4.1.5454.1.40.2.12
1.3.6.1.4.1.5454.1.40.2.13
1.3.6.1.4.1.5454.1.40.3.2
1.3.6.1.4.1.5454.1.40.3.3
Objects for Bandwidth Monitoring
1.3.6.1.4.1.5454.1.40.1.9.1
1.3.6.1.4.1.5454.1.40.1.9.2
1.3.6.1.4.1.5454.1.40.1.9.3
1.3.6.1.4.1.5454.1.40.1.9.4
Objects for Alarm Monitoring
1.3.6.1.4.1.5454.1.40.3.4.1.1
1.3.6.1.4.1.5454.1.40.3.4.1.2
1.3.6.1.4.1.5454.1.40.3.4.2
1.3.6.1.4.1.5454.1.40.3.4.3
Trango Broadband Wireless — Atlas5010
Name
verUnitType
sysswAutoScanMUSignal
sysDefaultOpmode
sysCurrentOpmode
sysActivateOpmode
sysipconfigIpAddress
sysipconfigSubnet
sysipconfigDefaultGateway
sysipconfigChange
rfPeerDeviceID
rfActiveChannel
rfActivePolarization
rfSpeed
rfTxPower
sysRemarks
rfRSSI
rfAssociated
ruReboot
ruDistance
systrafficEthInOctets
systrafficEthOutOctets
systrafficRfInOctets
systrafficRfOutOctets
trapTrapDstEntry
trapTrapDstEnabling
trapTrapIpAddress
trapTrapCommStr
Description
Returns radios unit type
(0 = RU, 1= MU)
Returns value of Auto Scan switch
(0 = off,1 = on)
Returns defaultOpmode setting
(0 = off,1 = on)
Returns current opmode setting
(0 = off,1 = on)
Turns opmode on
Sets IP address
Sets subnet
Set default gateway
Activates IP address change
Configure PeerID
Displays current channel
Displays current antenna polarization
Displays current Speed setting
Displays current transmit power (dBm)
Display radios remarks
Displays RSSI value (dBm)
Displays current association status
(0 = disassociated,1 = associated)
Reboots RU
Displays current ru distance
Displays Ethernet in (bytes)
Displays Ethernet out (bytes)
Displays RF in (bytes)
Displays RF out (bytes)
Enable/Disable trap
Set destination trap IP
Set trap community string
page 31
