Appendix B
NEMA Rating:
Shock:

Power Parameters

Input Voltage:
Current Cons.:

Power Supply

Type:
Safety:
EMI:
Input:
Plug Type:
Output:
Max current:
Antennae
Integrated Antenna (for Atlas5010-INT)
Frequency range: 5250-5850 MHz
Gain:
Front/Back Ratio
E-Plane Beamwidth:
H-Plane Beamwidth:
Polarization:
Port/Port Isolation:
Cross Pol Rejection:
VSWR:
Package:
Dimensions:
Weight:
Azimuth/El Adjust:
Temp Range:
Wind speed operational: 100 mph (160 km/hr)
Wind speed survival :
FCC Certified External Antennae (for Atlas5010-EXT)
Radiowaves models:
See Radiowaves, Inc. for specifications and details .
Trango Broadband Wireless — Atlas5010
NEMA 4
Sustain 3 axis drop from 5 feet
Input voltage range at unit is 10.5 VDC to 24 VDC max. Power is supplied
on Ethernet cable using junction box provided with up to 330 foot 24 AWG
STP cable.
Max 600 mA in transmit and receive modes using 24 V standard adapter (12 W) with
short Ethernet cable from Junction box to radio.
Switch mode wall mount transformer
PSE, UL, CUL, GS
FCC Class B, VCC-II, CE
90 – 255 VAC
Includes 4 plug blades for to allow use in US, Europe, UK and Australia
24 VDC +/- 1 V
750 mA
23 dBi +/- 1 dB
>35 dB
> 9 degrees typical
> 9 degrees typical
Vertical and Horizontal
40 dB typ
25 dB typ
<1.7:1
Alumininum backplate with plastic radome.
14.6"x 14.6"x 1.58" (371mm x 371mm x 40mm)
5.5 lbs (2.5 kg)
+/-30 degrees
-40 deg F to +160 deg F (-40 deg C to +60 deg C)
140 mph (220 km/hr)
SPD4-5.2, SPD3-5.2, SPD2-5.2, SPD1-5.2
Specifications
page 45
